Product Specifications
Prod Model: |
HZJY-510 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Power: |
Electronic |
Usage: |
Insulation Testing Machine |
Max Test Voltage: |
20000V |
Testing Resistance Range: |
0.5-2000g |
Anti Electric Interference Ability: |
2mA |
Accuracy: |
±(5%+5) |
Power Supply: |
180-270VAC ,50Hz/60Hz±1% |
Working Temperature: |
-10-40 |
Humidity: |
20-90%. |
Warranty: |
12 Months |
Product Description
20KV Digital Withstand Voltage Testing Meter Megger
I.Product Description for 20KV Digital Withstand Voltage Testing Meter Megger:
Insulation resistance tester is used for insulation resistance test and insulation material withstand voltage test.
II.Features for 20KV Digital Withstand Voltage Testing Meter Megger:
1,Strong anti electric interference ability 2mA(50Hz),
2,Short-circuit current of the testing power>5mA,Maximum 15mA.Adapting to testing of large-capacity and high inductance.
3,Wide resistance testing range:0.5MΩ~200000MΩ.Accurate and high resolution
4,Wide voltage testing range,0.25,0.5,1,2.5,5,10,15,20kV optional,the voltage can be adjusted smoothly from 0V to the needed.
5,Timekeeping function,Analyzing the absorption ratio and polarization index
III.Parameter for HZ 20KV digital megger Insulation resistance tester:
Model | Testing Voltage | Accuracy | Short Circuit Current |
HZ-5kV | 0~0.25,0.5,1,2.5,5kV | ±(5%+10V) | >5mA |
HZ-10kV | 0.5,1,2.5,5,10kV | ±(5%+10V) | >5mA |
HZ-15kV | 1,2.5,5,10,15kV | ±(5%+10V) | >5mA |
HZ-20kV | 0.5,1,2.5,5,10,20kV | ±(5%+10V) | >5mA |
Range and Accuracy for 20KV Digital Withstand Voltage Testing Meter Megger :
Range(limited voltage) | Resistance Measurement Range | Accuracy |
20MΩ/500V | 0.5~19.99MΩ | ±(5%+5) |
200MΩ/1000V | 5.0~199.9MΩ | ±(5%+5) |
2GΩ | 0.05~1.999GΩ | ±(5%+5) |
20GΩ | 0.5~19.99GΩ | ±(5%+5) |
200GΩ | 50~199.9GΩ | ±(10%+10) |
2000GΩ | 50~1999GΩ | ±(20%+10) |
GΩ range scaling voltage 2.5kV |
Anti Electric Interference Ability | 2mA(50Hz) |
Timekeeping and Alarm Function | Maximum display of Stopwatch:19min and 59s;20 min a cycle. Sound reporting points:15s, 60s and every minute.resistance reading for 5s.when the measured resistance is less than the lower limit of the range and reading invalid ,it continuously sound alarm |
Display Fable | Three LED digital meter, respectively show the test voltage, resistance and time |
Power Supply | By enclosing 1.2V / 2000mAh NiMH rechargeable batteries 10, DC12V power supply. With AC (50 / 60Hz) 220V access port to Charge the battery or floating charge |
Using Environment | Temperature:0~40ºC | humidity:20~90% |
Dimension | 315×240×155mm3 |
Weight | 5kg |
IV.FAQ for 20KV Digital Withstand Voltage Testing Meter Megger:
1. Q:What is voltage of megger insulation resistance meter / tester?
A:Voltage: 20KV
2. Q:What is the resistance test range of megger insulation resistance meter / tester ?
3. Q:What is Warranty of megger insulation resistance meter / tester ?
A:12 months, during this time we can repair or change new one to you.
4. Q:Is English version available?
A: YES! English is available.
5. Q:Have you ever sold to any country?
A:We have ever sold to Philippines, Thailand, and Brazil and so on.
6. Q:Could you please send me the specification or catalogue to my email?
A:Yes, May I know your email? We send now.
