Price: | Negotiable/Piece |
---|---|
Trade Terms: | FOB |
Min Order: | 1/Piece |
Pay Type: | T/T |
Technical specifications | |||
Model | F-I-P1.563 | F-I-P1.923 | F-I-P2.5 |
Product name | Indoor full color LED display | ||
LED wave length | R: 620-625nm, G: 520-525nm, B: 465-470nm | ||
Pixel | |||
Pixel pitch | 1.563mm | 1.923mm | 2.5mm |
Pixel configuration | 1R1G1B | 1R1G1B | 1R1G1B |
LED Encapsulation | SMD1010 | SMD1010 | SMD2121 |
Module | |||
Resolution of module | 128*96=12,288 Dots | 104*78=8,112 Dots | 64*32=2048Dots |
Size of module | 200*150 | 200*150 | 160*80 |
Cabinet | |||
Resolution of cabinet | 384*384= | 312*312 | 192*192 |
Size of standard cabinet | 600(L) x 600(H) mm | 600(L) x 600(H) mm | 480(L) x 480(H) mm |
Cabinet material | Aluminum alloy | ||
Thickness of cabinet | 60mm | ||
Weight of cabinet | 8 kg | 8 kg | 6 kg |
Panel | |||
Pixel density | 409,600dots/m² | 270,400 dots/m² | 160,000 dots/m² |
Brightness | ≥1200CD / m² | ≥1200CD / m² | ≥1500CD / m² |
Grey scale | 12 bits/4096 levels | 12 bits/4096 levels | 12 bits/4096 levels |
Colors | 68.7 Billion | 68.7 Billion | 68.7 Billion |
View angle | H:150°; V:120° | H:150°; V:120° | H:150°; V:120° |
Optimal view distance | 2-20M | 2-20M | 2-20M |
Average power consumption/sqm | 500 Watts | 500 Watts | 500 Watts |
Max. power consumption | 1200 Watts /m2 | 1200 Watts /m2 | 1200 Watts /m2 |
Refresh rate | ≥1200HZ | ≥1200HZ | ≥1200HZ |
IP rating | IP31 Waterproof & dustproof ( front and back ) | ||
Control | |||
Driving mode | Constant current driving | ||
1/32 scan | 1/26 scan | 1/16 scan | |
Signal Interface | Ethernet (network) interface | ||
Support input source | RF,RGB,RGBHV, HDTV, SDI, HD-SDI, S-video, composite,DVI,etc | ||
Control mode | Synchronous display with control PC by DVI | ||
Control distance | Cat5 Ethernet cable ≤120m ; Optical fiber : 10000m | ||
Operation | |||
Power supply | 110V/220 V AC , 50HZ/60 Hz | ||
MTBF | ≥5,000 hours | ≥5,000 hours | ≥5,000 hours |
Lifespan | 75,000 ~100,000 hours | 75,000 ~100,000 hours | 75,000 ~100,000 hours |
Out of control rate | <0.0001 | <0.0001 | <0.0001 |
Operation temperature | Minus 20ºC~60ºC | Minus 20ºC~60ºC | Minus 20ºC~60ºC |
Operation humidity | 10%~95%RH | 10%~95%RH | 10%~95%RH |
Storage & Application | |||
Storage temperature | Minus 40ºC~85ºC | Minus 40ºC~85ºC | Minus 40ºC~85ºC |
Storage humidity | 30%~60%RH | 30%~60%RH | 30%~60%RH |
Application | For indoor use , for rental |
Prod Model: | F-I-P1.563 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Light Source: | LED |
Housing Material: | Metallic or Aluminum |
Appearance: | Square |
Type: | Flat-Type |
Voltage: | 100-240V |
Certification: | CE, RoHS |
