Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Manufacturing Technology: |
Optoelectronic Semiconductor |
| Material: |
Element Semiconductor |
| Type: |
P-type Semiconductor |
| Package: |
Customized |
Product Description
- 100mW 532nm with TEC control
- CDRH CLASS: CLASS IIIb
- CW&Modulation
- Output Power>200mW
- Wide Operating temperature
200mW Green Laser Module- HL532-200D
About us
We are a leading manufacturer specialized in designing and manufacturing different kinds of bore sighter and laser sighter in China with experience of more than 10 years, manufacturing according to ISO9001: 2008 quality control system guidline. All of our products are FDA certified and OEM service offered.
Parameter |
Spec. |
Test Conditions |
Wavelength |
532 nm |
T c = 25° C |
Output Power |
> 200mw |
T c = 25° C |
Laser Modes |
CW & Pulse |
TTL modulation |
Transverse mode |
TEM 00 |
|
Output Aperture |
< 4 mm |
Factory fixed |
Beam Size |
< 20 mm |
Factory fixed @ 20m |
Divergence |
< 1 mrad |
T c = 25 ± 3° C |
Operating Current |
< 5A |
T c = 25± 3° C |
Operating Voltage |
90-250VAC / (50-60Hz) |
|
Operating Temp. |
0° C ~ 45° C |
|
Storage Temp. |
-20° C ~ 70° C |
|
CDRH Class |
Class IIIb |
|
MTTF |
5000 Hrs. |
T c = 25± 3° C |
Dimensions 42 x 42 x 97mm |
|
|
Elite Optoelectronics Co., Ltd. is a leading designer and manufacturer of laser diode modules, DPSS laser module and laser instruments. With experienced R&D team and large-scaled production capacity, Elite is world-class laser diode module supplier. Elite's products have been successfully used in a wide range of diversified applications from industrial level, laser pointer, barcode scan, medical instruments, detecting instruments, laser component, bore sight, laser collimator, laser performance system, laser tools etc.
Elite's product line includes an extensive range of laser modules and systems for the laser/electro-optic industry. Our laser modules come in wavelengths ranging from 405nm to 980 nm with various power ranges. With certificates of ISO 9001: 2000, FDA, IEC, GB, etc, we are assuring our customer with quality, reliable and consistent products deliver.
Elite has successfully developed the Industrial Green Laser Module (GLM) which has a wide working temperature ranging from 0-45° C. The GLM is in stable operation, low power output and small size of 8 x 28mm, 10 x 30mm.
Share your ideas, Elite's experienced, highly skilled and dedicated technical staff will help you to solve your design problem and help with your selection of either stock or customized products for special application.
