More powerful function via Remote Meter or PC
#Diversified load control modes : Manual, Light ON/OFF, Light ON+ Timer, Time Control
#Battery type option: Gel, sealed, flooded and USER
#Real-time monitor
#Programmable parameters
#LVD or SOC load disconnect function
#Energy statistics function
#Electronic protections:Features:# Three system voltage configuration : 12V, 24V or 12V/24V auto work
# High efficiency PWM charging with temperature compensation
# 3 LEDs shows PV charging, battery and load status
# External temperature sensor interface
# RS-485 bus communication
# Open standard Modbus communication protocol
# Software update function
Electronic protections:
# PV short circuit # Battery Over discharge Battery reverse polarity # Load overload Overheating # PV reverse polarity # Battery overcharge # Load short circuit
Application:
Solar home system
Solar lighting system
Solar road signals
Solar surveillance
Solar RVs and boats
Small solar power station
10A 12V 24V SOLAR CHARGE CONTROLLER (no meter include )
|
Model |
LS1024B |
|
Nominal system voltage |
12V/24V |
|
Rated battery current |
10A |
|
Rated loadcurrent |
10A |
|
Max. PV open circuit voltage |
50V |
|
Equalize charging voltage |
Gel: ----, Sealed: 14.6V, Flooded: 14.8V ,User-defined: 9~17V |
|
Boost charging voltage |
Gel: 14.2V, Sealed: 14.4V, Flooded: 14.6V ,User-defined: 9~17V |
|
Float charging voltage |
Gel / Sealed / Flooded:13.8V , User-defined: 9~17V |
|
Low voltage reconnect voltage |
Gel / Sealed / Flooded:12.6V ,User-defined: 9~17V |
|
Low voltage disconnect voltage |
Gel / Sealed / Flooded:11.1V ,User-defined: 9~17V |
|
Charge circuit voltage drop |
≤0.26V |
|
Discharge circuit voltage drop |
≤0.15V |
|
Self-consumption |
≤6mA |
|
Temp. compensation |
-5mV/ºC/2V (ref) |
|
Overall dimension(mm) |
138x69.6x37 |
|
Mounting dimension |
126mm |
|
Mounting hole size |
Φ4.5 |
|
Terminal |
4mm² |
|
Weight |
130.6g |
|
Working temperature |
-35ºC ~ +55ºC |
|
Storage temperature |
-35ºC ~ +80ºC |
|
Humidity |
≤95% N.C. |
|
Enclosure |
IP30 |
