15.6" LED Widescreen Touch Screen Computer
| Price: |
US $ 90-125/Piece |
| Trade Terms: |
FOB,CFR,EXW |
| Min Order: |
1/Piece |
| Pay Type: |
T/T,Money Gram,Western Union |
15.6" LED Widescreen Touch Screen Computer
Specifiction
1366x768
VGA+USB
OEM, ODM
4 wire or 5 wire optional
A+ grade quality, 3 years warranty
Factory: 300 workers, welcome to visit
Customized logo is ok for free ( MOQ)
sizes from 7" to 65"
| Model: 156HD (A+ grade) |
| Panel size | 15.6 inch LED Touch Screen Monitor (Slim side design) |
| Display area | 305*228mm |
| Standard Resolution | 1366*768 |
| Number of Colors | 16.7M |
| Brightness | 300cd/m 2 |
| Response time | 5ms |
| View angle | Horizontal: 160° |
| Vertical: 140° |
| Contrase ratio | 500: 01: 00 |
| Video input format | (analog) RGB |
| Connector | VGA for video signal |
| USB for touch |
| Frequency | 30~80KHz/60~75Hz |
| Power supply | External Power Supply: 100 to 240V (DC 12V) |
| Operation Environment | Workable Temperature: -10 to 60° C Storage temperature: -20 to 70° C |
| Operate relative humidity: 20% to 80%; storage relative humidity: 10% to 90% |
| Touch model | 4-wire resistive touch |
| Optional | (5-wire resistive touch, SAW, Infrared touch optional) |
| Duration | 50000hours |
| touch validity | > 1, 000, 000 |
| Net weight | 6.0 Kgs/pcs, include stable mental base |
| Gross weight | 6.5 Kgs/pcs, include stable mental base |
| Power consumption | Max 30W |
| Setup (optional) | 1) provide wall brackets for wall-mounting, VESA 75mm& 100mm |
| 2) provide stable mental base to support the monitor |
| OSD control | AUTO, +, POWER, -, MENU |
| brightness, contrast ratio, auto adjustment, phase position, clock, Languages, function, Install, reset |
| Touch interface | USB or RS232 optional |
| Touch response time | 2ms |
| Certificate | CE, ROHS |
| Warranty | 1 year, provide spare parts |
| Monitor size(not include base) | 375*285*55mm |
| Each unit box size | 420*370*155mm |
| Package size | 4pcs in a carton, carton size: 650*450*430mm |
| Operation system | Windows, Linux, Mac. |
| Prod Model: |
156HD |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Factory Situation: |
300 Workers, Welcome to Visit |
| Touch Mode: |
Resistive, Infrared, Saw, Capacitive Is Optional |
| Interface: |
VGA+USB, RS232 Is Optional |
| Screen: |
Wide, Square Is Optional |
| Other Inputs: |
Add HDMI, TV, AV, DVI, USB Is Ok |
| Certificates: |
CE, RoHS, FCC |
| Sizes: |
From 7" to 65" |
| Cases: |
Plastic, Open Frame , Metal Case Optional |
| Customized Logo: |
Optional for Free |
| OEM: |
Yes |
| Type: |
Hand Held |
| Touch Screen: |
Touch Screen |
| Printer: |
Thermal |
| Certification: |
RoHS |
| CPU: |
Intel |
| System: |
Windows |
Shenzhen Hopestar Sci-Tech Co., Ltd. is a new high-tech enterprise, Devoted to the reaearch, development and sales of " Hope" series products, Our products has CCC certificate, Main products including Moniotrs/TVS/all in one / Advertising player.
We offer high quality products and best after sales services, we adhere to the principle of " Credibility frist and service-Oriented, we have set up department of scientific reasearch, management and production, the productino base is 3, 000 squre meters, with a dust-free professional workshop and 4 supporting comprehensive production lines.
Our Hot-selling monitors as below;
7"8"9"10.4"12.1"13.3"14" for car monitor
15.6"17.3"18.5"21.5"23"23.6" for LED monitor
15"17"18.5"19"20"21.5"22". 23"23.6" for LCD monitor
7"8"10.4"12"15"17"19"21.5"22"26"32"42"46"55"65" for touch screen monitor
7"8"10.4"12"15"17"19"21.5"22"26"32"42"46"55"65" for CCTV monitor
7"8"10.4"12"15"17"19"21.5"22"26"32"42"46"55"65" for open frame monitor
Our company has a high quality sales team, we have developed a large number of agents and distributors, established a worldwide sales network and a comprehensive after sales service system.
We are willing to work together with new and old customer for creating a brilliant future.
