Product Specifications
| Prod Model: |
S-240W-15V |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Output: |
15V |
| OEM: |
Yes |
| Size: |
215*110*50mm |
| Weight: |
0.85kg |
| Output Type: |
Single |
| Output Power: |
201 - 300W |
| Input Voltage: |
110-220V |
| Voltage Regulating Mode: |
Frequency Modulation Type |
| Connection Mode: |
Series Switching Power Supply |
| Starting Mode: |
Self-excited Switching Power Supply |
| Warranty: |
2 Years |
| Power Supplying System: |
Level 1 Power Distribution Equipment |
| Certification: |
CE |
| Brand: |
Chux |
Product Description
15V switching mode power supply 240w (S-240W-15V)
Feature:
1. Low price and high reliability of LED switching power supply
2.105 degree output capacitor
3. AC input power suitable for the world
4. High efficiency and low operation temperature
5. Soft-start current can reduce the AC input impact effecticly
6. Compact size, light weight
7.100% full-load bum-in test
8.24hours testing
9. Installed with EMI filter, minimum wave.
Packing:
Size: 215*110*50 mm
20pcs /ctn 0.85kg
SPECIFICATION
240W Single Output Switching Power Supply (SMPS) S-240W |
| MODEL | S-240-5 | S-240-12 | S-240-15 | S-240-24 | S-240-27 | S-240-48 |
| DC VOLTAGE | 5V | 12V | 15V | 24V | 27V | 48V |
| RATED CURRENT | 40A | 18A | 15A | 10A | 8A | 5A |
| CURRENT RANGE | 0 ~ 40A | 0 ~ 18A | 0 ~ 15A | 0 ~ 10A | 0 ~ 8A | 0 ~ 5A |
| RATED POWER | 200W | 240W | 240W | 240W | 236W | 238W |
| RIPPLE & NOISE (max. ) | 150mVp-p | 150mVp-p | 180mVp-p | 180mVp-p | 200mVp-p | 240mVp-p |
| VOLTAGE ADJ. RANGE | 4.5 ~ 5.7V | 10 ~ 13.2V | 13.5 ~ 18V | 20 ~ 26.4V | 26 ~ 32V | 41 ~ 56V |
| VOLTAGE TOLERANCE | ± 2.0% | ± 1.0% | ± 1.0% | ± 1.0% | ± 1.0% | ± 1.0% |
| LINE REGULATION | ± 0.5% | ± 0.5% | ± 0.5% | ± 0.5% | ± 0.5% | ± 0.5% |
| LOAD REGULATION | ± 1.0% | ± 0.5% | ± 0.5% | ± 0.5% | ± 0.5% | ± 0.5% |
| SETUP, RISE, HOLD TIME | 2000ms, 20ms, 24ms at full load |
| VOLTAGE RANGE | 88 ~ 132VAC / 176 ~ 264VAC by switch 248 ~ 370VDC |
| FREQUENCY RANGE | 47 ~ 63Hz |
| EFFICIENCY (Typ. ) | 77% | 80% | 82% | 83% | 84% | 87% |
| AC CURRENT | 15A/115VAC 30A/230VAC |
| INRUSH CURRENT (max. ) | 18A/115VAC 36A/230VAC |
| LEAKAGE CURRENT | < 3.5mA / 240VAC |
| OVERLOAD | 105 ~ 135% rated output power |
| Protection type: Hiccup mode, recovers automatically after fault condition is removed. |
| OVER VOLTAGE | 5.75 ~ 6.75V | 13.8 ~ 16.2V | 18 ~ 21V | 27.6 ~ 32.4V | 33.7 ~ 39.2V | 57.6 ~ 67.2V |
| Protection type: Hiccup mode, recovers automatically after fault condition is removed. |
| FAN CONTROL O. T. P. | RTH1 ≥ 65º C FAN ON, ≤ 55º C FAN OFF, ≥ 70º C (5 ~ 15V) |
| RTH1 ≥ 70º C FAN ON, ≤ 65º C FAN OFF, ≥ 80º C (24 ~ 48V) |
| Protection type: Hiccup mode, recovers automatically after fault condition is removed. |
| WORKING TEMP. | -10 ~ +60º C (Refer to output load derating curve) |
| WORKING HUMIDITY | 20 ~ 90% RH non-condensing |
| STORAGE TEMP., HUMIDITY | -20 ~ +60º C, 10 ~ 95% RH |
| TEMP. COEFFICIENT | ± 0.03%/º C (0 ~ 50º C) |
| VIBRATION | 10 ~ 500Hz, 2G 10min. /1cycle, 60min. each along X, Y, Z axes |
| SAFETY STANDARDS | Design refer to UL1950 |
| WITHSTAND VOLTAGE | I/P-O/P: 1.5KVAC I/P-FG: 0.5KVAC O/P-FG: 0.5KVAC |
| ISOLATION RESISTANCE | I/P-O/P, I/P-FG, O/P-FG: 100M Ohms/500VDC |
| MTBF | 188.7K hrs min. MIL-HDBK-217F (25º C) |
| DIMENSION | 215*115*50mm (L*W*H) |
| PACKING | 0.939Kg; 15pcs/13.74Kg/0.0263CMB
|
