Dear customer: About the SMS modem, we have four itmes, different item different function and of course different price, we have wavecom modem with Q2303, Q2403, Q2406, Q24Plus.
Q2303 support SMS. 900/1800MHz
Q2403 support SMS and MMS. 900/1800MHz
Q2406 support SMS, MMS and TCP protocol. 900/1800MHz
Q24plus suport SMS, MMS, remote and EDGE. 850/900/1800/1900MHz
This is the new RJ45 module
Introduction
SF mn8 is a industry equipment which has 8 ports modem for the
SMS/MMS (GSM/GPRS MODEL ), used FranceWAVECOM module. Stable
And reliable. Through the RJ45 network port access LAN. Its appearance
Based on standard 1U chassis design, fit into a standard room rack.
Product features
Adaptive Ethernet (RJ45) interface
Based on france WAVECOM module, Stable and reliable.
8 port in parallel
Supports both China Mobile and China Unicom SIM cards
Industrial grade quality standards
Standard 1U chassis design
Technology parameter
Radio- equency performance
Double frequency (EGSM/GPRS 900/1800 MHz, EGSM900/1900MHz)
Rx (EGSM 900): 925 to 960 MHz
Tx (EGSM 900): 880 to 915 MHz
Rx (GSM 1800): 1805 to 1880 MHz
Tx (GSM 1800): 1710 to 1785 MHz
Rx (GSM 1900): 1930 to 1990 MHz
Tx (GSM 1900): 1850 to 1910 MHz
SMS: Support MT, MO, CB, Text and PDU mode
Power consumption:
Voltage: 3.6V
Class4(2W@900MHz)
Class1(1W@1800/1900MHz)
Single-channel input V: 5V-28V
Single-channel input C: MAX 1.7A, average 270MA
Baud rate: Default 9600bps(SMS), 115200bps(MMS)
Ethernet: 10/100M adapter
Default IP Address: 192.168.0.233
Deploy: TELNET or http
Transmit-receive rate: 720-900 sms /Hour
AT command control standards: GSM07.07, GSM07.05
Antenna: 50 ohm, 3dB gain
Size: Standard 1U
Range of temperature:
-20 to +50 working
-20 to +70 conserve
Input: 220AC/50~60HZ
Network interface: A 10/100M adapter
SIM interface: 8 SIM cards slot
Antenna interface: 8 SMA antenna
Installation
Step A hardware
SF-MN8 with a crossover cable to connect your desktop or laptop. With a
Straight-through network cable connection to the Ethernet port on the
Switch or router
Turn the SIM card into the slot
Connect an antenna to the SMA interface
Connect the power and turn the power switch
Step B software
You can find some files in the CD, get into "RJ 45 Modem Driver":
Select "uprade. Exe" and install it.
After finishing install and click it.
Then you can change its default IP address which is within the same
Network segment to your local area network.
Driver installation
Before you mapping ports from an IP address, it's necessary to install:
Finish its installation, configurate as follows
Finished. Then you can find all the com ports in "Device Manager":
