2014 Cheap and High Quality Smart Card
Smart card Specification:
1. Size: 86X54X0.8mm
2. Material: PVC /PETG/PET/ABS/PLA
3. Chip: OPTIONAL
4. Work frequency: 125kHz
5. Double side pure white
6. Double side liminated, high glossing surface
7. With chip number inkjet printing
8. Operation distance: 3-10cm
9: Packing: 200PCS/inner box, 5000PCS/carton/32kgs/0.03cbm
Smart card craftworks Details
1. Printing options
- Pantone color printing( common is 2-3 colors, can be more color in extra cost);
- gold or silver color background;
- Hot stamp foil color ( gold, silver, laser red gold etc);
- Security logo printing;
- Hologram logo.
2. Size
- CR80 Size: 2.125*3.375 inch (86*54 mm)or customized die cut shape;
- Common size: 12mil(0.3mm), 14mil(0.36mm), 18mil(0.45mm), 20mil(0.5mm), 30mil(0.76mm);
- Uncommon size: 24mil(0.6mm), 40mil (1.0mm);
3. Surface Processing Craft
- Lamination Glossy, Frosted, Matt, Sport UV, Epoxy or others special request.
4. Material
PVC/PETG/PET/ABS/PLA
5. Optional Crafts
- Embossing name, number and date ( gold or silver color for options);
- Barcode, QR code, Signature panel, magnetic strip, scratch-off panel, UV;
6. Magnetic Stripes(LoCo/ HiCo)
1). Low coercivity (LoCo) and High coercivity (HiCo) magnetic stripes. Encode data into track 1, 2, 3;
2). Magnetic size: 8mm/12.5mm;
7. Scratch-Off Panels
It is commonly used to cover surprise gifts, codes, surprise discounts, data, icons etc. The client/user receives the card in the mail, at a store, or event and then gets to simply scratch off the panel to reveal the information. You can include more than one scratch panel on your design, however, too many panels can leave residual "scratch-off" material on your cards.
8. Technic Specification for rfid smart card
Chips Available: ISSI 4439, ISSI S70, QR2217, NXP S50, NXP S70, FM1108, etc.
For CPU card: FM1208, ISSI4456, NXP PLUS, P5CD12A4T0B, etc.
Card Size: 85.5*54*0.76mm or customized size
Storge Temperature: -20~50
Operating Temperature: -20~50
Frequency: 13.56MHz
EEROM write time: 2.5ms
EEROM write endurance: 10, 000cycles
EEROM data retention: 10years
Operating distance: 2.5~10cm
Memory Capacity: 1KB, 4KB, 8KB
Read/Write: Read and write
Card Specifications
Card type
RFID card/smart card/contact IC card/magstrip card/ID card
Material:
PVC/PAPER/ABS/PET/PS/Anti-metal Absorbing Material/Epoxy/Silicone
Size:
ISO CR80 Standard:85.5*54mm, or customized
Thickness:
Credit card standard: 0.76mm
RFID card standard: 0.86mm
Contact IC card Standard: 0.81mm,
0.3mm~1.8mm according to your request
Chips and frequency
LF(125KHz)
ISO 125KHz ,TK4100/EM4100/EM4102/EM4200,EM4305,
T5577/T5567/T5557 rfid proximity cards
HF(13.56MHz)
ISO 14443A:
classic 1k , 4k, FM08, Ultralight, Ultralight C, Ntag203,
DESFire EV1 2k/4k/8k
ISO15693:
I CODE 2, I CODE SLI, I CODE SLI-X, Tag-IT TI2048 / TI256.
UHF (860z-960MHz)
ISO18000-6B: UCODE HSL
ISO18000-6C: Alien H2/H3,Impinj,U CODE G2
Write cycle
100000 time
Reading distance
LH,HF(1-10cm)
Up to the antenna, environment, size, material etc.
UHF(above 3 m)
Crafts
CMYK offset printing, Silk-screen printing,Thermal printing, Digit printing, Magnetic stripe.
Barcode/QR code, Golden/silver hot-stamping, Signature panel, Series number printing,
UV printing, UID number printing, laser engrave etc.
Glossy, Matt, Frosted finish,Transparent
Applications
Public transportation ( Metro card, Bus IC card etc.)
Access management
Event ticketing
Gaming
Security and Identification
Packing
For standard card(85.5*54*0.86mm):
inner box: 215×90×55mm (200pcs/box) , carton: 485×230×305mm( 25boxes/CTN)
Standard size card weight (only for reference) : 1,000pcs is for 6kg
Packing way can according to your request
Samples
Free samples are available upon request
