Price: | US $ 4500-5500set |
---|---|
Trade Terms: | FOB |
Min Order: | 1set |
Pay Type: | L/C,T/T,Western Union |
Model | SSH-6030 | SSH-8030 | SSH-10030 | SSH-12030 | SSH-16030 | SSH-20030 | SSH-30030 |
Block type | PISTON | PISTON | PISTON | PISTON | PISTON | PISTON | PISTON |
Volume(m3/min) | 0.6 | 0.8 | 1.0 | 1.2 | 1.6 | 2.0 | 3.0 |
W.Pressure(Mpa) | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 | 3.0 |
RPM(r/min) | 830 | 800 | 780 | 780 | 830 | 830 | 780 |
Lubrication | splash | splash | splash | splash | splash | splash | splash |
drive | belt | belt | belt | belt | belt | belt | belt |
cooling | Air cooling | Air cooling | Air cooling | Air cooling | Air cooling | Air cooling | Air cooling |
Motor power(Kw) | 7.5 | 7.5 | 11 | 15 | 18.5 | 2X11 | 30 |
Power source(v/Hz) | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 |
noise(dB (A)) | ≤72 | ≤72 | ≤78 | ≤78 | ≤85 | ≤85 | ≤85 |
Cylinders diameter(mm) | 2X¢95 ¢55 | 2X¢100 ¢55 | 2X¢120 ¢65 | 2X¢120 ¢65 | 2X¢135 ¢120 ¢65 | 4X¢120 2X¢55 | ¢210 ¢120 ¢100 |
size(mm) | 1470(L) 530(W) 1020(H) | 1490(L) 600(W) 1160(H) | 1550(L) 730(W) 1280(H) | 1620(L) 730(W) 1280(H) | 1900(L) 850(W) 1600(H) | 1900(L) 900(W) 1400(H) | 1850(L) 1000(W) 1100(H) |
weight(Kg) | 290 | 430 | 480 | 520 | 600 | 600 | 1150 |
Model | SSH-8040 | SSH-12040 | SSH-16040 | SSH-20040 | SSH-30040 | SSH-6060 | SSH-12060 |
Block type | PISTON | PISTON | PISTON | PISTON | PISTON | PISTON | PISTON |
Volume(m3/min) | 0.8 | 1.2 | 1.6 | 1.8 | 3.0 | 0.6 | 1.2 |
W.Pressure(Mpa) | 4.0 | 4.0 | 4.0 | 4.0 | 4.0 | 6.0 | 6.0 |
RPM(r/min) | 780 | 800 | 780 | 780 | 850 | 780 | 780 |
Lubrication | splash | splash | splash | splash | splash | splash | splash |
drive | belt | belt | belt | belt | belt | belt | belt |
cooling | Air cooling | Air cooling | Air cooling | Air cooling | Air cooling | Air cooling | Air cooling |
Motor power(Kw) | 11 | 18.5 | 18.5 | 22 | 30 | 15 | 22 |
Power source(v/Hz) | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 | 380/50 |
noise(dB (A)) | ≤85 | ≤85 | ≤85 | ≤85 | ≤85 | ≤85 | ≤85 |
Cylinders diameter(mm) | ¢125 ¢95+¢36 ¢65 | ¢160 ¢100 ¢65 | 2X¢135 ¢100 ¢55 | 2X¢120 2X¢55 | ¢210 ¢120 ¢100 | ¢125 ¢95+¢34 ¢65 | 2X¢130 ¢80 ¢42 |
size(mm) | 1650(L) 730(W) 1150(H) | 1900(L) 850(W) 1600(H) | 1750(L) 750(W) 1100(H) | 1900(L) 950(W) 1400(H) | 1950 (L) 1000 (W) 1100(H) | 1650(L) 730(W) 1150(H) | 1700 (L) 850(W) 1300(H) |
weight(Kg) | 550 | 560 | 600 | 600 | 1150 | 550 | 600 |
Prod Model: | SSH-10030 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Type: | Piston |
Performance: | Low Noise |
Drive Mode: | Electric |
Power Source: | AC Power |
Configuration: | Stationary |
Material: | Cast |
Piston Type: | Semi-Closed |
Lubrication Style: | Lubricated |
Mute: | Not Mute |
Application: | Piston |
