Product Specifications
| Prod Model: |
KH-200GF |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Cooling Method: |
Water Cooling |
| Stroke: |
Four Stroke |
| Installation Method: |
Fixed |
| Type: |
Basic Diesel Generator |
Product Description
1. Cummins diesel engine
2. OEM service from cummins
3. Suitable for industrial use
4. Low oil consumption
5. Convenient to operate
|
3. Genset Technical Data: |
|
Gensets model |
KH-200GF |
|
Prime power |
200KW/250kVA |
|
Stangby power |
360KW |
|
Rated speed |
1500RPM |
|
Output frequency |
50Hz |
|
Power Factor |
0.8(lagging) |
|
Phase |
3 |
|
Rated voltage |
380/220V |
|
Dimensions(mm) (L× W× H) |
2600*1120*1670 |
|
Genset Weight(kg) |
2700 |
|
Prime Power: |
|
This rating is for the supply of continuous electrical power (at variable load). There is no limit on the annual hours of operation and 10% overload power can be supplied for 1 hour in 12. |
|
Standby power: |
|
This rating is for the supply of continuous electrical power (at variable load) in the event of a utility power failure. No overload is permitted. |
|
Rated voltage: |
|
Available with customer requirements. |
|
4. Specification of diesel engine: |
|
Engine brand |
Volvo |
|
Engine model |
TAD734GE |
|
Number of Cylinders |
6 |
|
Cylinder arrangement |
Vertical in-line |
|
Cycle |
Four stroke |
|
Aspiration |
Turbocharged, Air/Air cooling |
|
Fuel System |
Elec. Injection, Common Rail |
|
Bore× Stroke (mm× mm) |
108 x 130 |
|
Displacement (Liter) |
7.15 |
|
Compression Ratio |
17.0: 1 |
|
Speed Governor |
Heinzman Mechanical Governor |
|
Cooling System |
Forced Water Cooling Cycle |
|
Speed Stability (%) |
≤ 1% |
|
Total lubrication system capacity (L) |
29 |
|
Fuel Consumption at 100% Load (g/kwh) |
204 |
|
Starting Method |
DC24V Electrical starting |
Our company is maunfacturer of diesel generator, the OEM of cummins engines with certify of CE, ISO9001.
Mainly produce and sale diesel gen-sets, inland diesel gen-sets from 3-3000kVA, marine energent diesel gen-sets from 12-500kw and kinds of imported diesel gen-sets, movable power station, low-noise, multi-PCS connection, remote monitoring, gen-sets with ATS, gas gen-sets etc.
With good quality and low price.
