Product Specifications
| Prod Model: |
H1200 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
2M Transmission Analyzer
This product is Chinese-made, it has many names, like 2M Transmission Analyzer, 2M Bert tester, 2M data tester, and E1 BER Tester, but same function.
It is multi-functional and full- featured, hand-held, LCD display.
Accessories:
1. Main unit 1 PC
2. BNC-BNC testing cable 1 PC
3. BNC-L9 testing cable(75Ω ) 2 PCS
4. 120Ω Testing cable 1 PC
5. RS232 Serial Interface Cable 1 PC
6. USB to Serial Adapter 1 PC
7. Smart battery charger 1 PC
8. Top-grade waterproof carrying case 1 PC
9. PC management software CD 1 PC
10. Warranty card 1 PC
We also have other products, please see list below:
Our main products:
1. Fusion splicer: Sumitomo (type-66/-81c/z1c)
Fujikura (fsm-60s/70s/60r/70r/80s)
Fitel (S178A/S199M12)
Chinese fusion splicer (HSV6000)
2. OTDR: EXFO (axs-100/110, ftb-1/200/500),
JDSU (mts-2000/4000/6000/8000)
YOKOGAWA (AQ7275)
Ethernet tester: AXS-200/610/630/635/805/850/855)
3. Power meter (PPM-350c, FPM-300, HSV300P)
Light source (fls-300, HSV-300L)
VFL (fls-240, HSV-321)
Multi Loss tester (FOT-930, FOT-302)
4. Anritsu site master S331L, S331E, S332E.
5. Fiber cleaver (CT-30(A)/FC-6S), adapter, battery, electrode, connector, fiber tool kits
6. Fiber cable, patch cord, splice protector, adapter, closure, pigtail, optical switch, patch panel, etc...
7. Maintenance and repair, calibration service for the EXFO, Sumitomo, Fujikura, Anritsu.
Please contact Nancy if you need help.
Tel: 0086-0755-36934393
Item
|
Description
|
2M
|
Internal Clock
|
2048kb/s ± 10ppm
|
Frequency Deviation
|
±999ppm
|
Line Interface
|
75Ω (Unbalanced), 120Ω (Balanced); High Input Impedance > 2K W
|
Line Code
|
HDB3, AMI
|
Framing
|
Unframed, PCM30, PCM30CRC, PCM31, PCM31CRC
|
Receive Sensitivity
|
> -43dB
|
Tx Clock Source
|
Internal, Interface and External 2MHz clock or signal
|
Pulse Mask Measurement
|
Comply with G.703
|
Jitter Measurement
|
Comply with O.172
|
Frequency Measurement
|
Accuracy: ±1Hz
|
Offset Measurement
|
Accuracy: ±1ppm Range: -999ppm ~ +999ppm
|
VF Injection
|
Frequency: 200Hz ~ 3400Hz, Step: 10Hz
|
Level: -60dBm ~ +3dBm
|
VF Measurement
|
Frequency: 200Hz ~ 3400Hz, Accuracy: ±1Hz
|
Level range :-60.00dBm ~ +3.14dBm -60.00dBm ~ -21.00dBm, accuracy: ±2.87dBm -20.00dBm ~ +3.14dBm, accuracy: ±0.21dBm
|
Delay Measurement
|
Accuracy: ±1μs
|
G.703 CO
|
Line Rate
|
64kb/s ± 100ppm
|
Line Interface
|
120Ω, Balanced
|
Line Code
|
AMI
|
Datacom
|
Line Interfaces
|
V.24, V.35, V.36, X.21, RS-449, RS-485, EIA-530, EIA-530A
|
Data Rate
|
ASYNC
|
300, 600bit/s, 1.2, 2.4, 4.8, 7.2, 9.6, 19.2, 38.4kb/s
|
SYNC
|
300, 600bit/s, 1.2, 2.4, 4.8, 7.2, 9.6, 19.2, 38.4kb/s, N×64kb/s ( N=1 ~ 32),4M,8Mkb/s
|
Test Patterns
|
PRBS
|
2 23 -1,2 20 -1, 2 15 -1, 2 11 -1, 2 9 -1,2 6 -1
|
Fixed Code
|
1111, 0000, 1010
|
16-BIT
|
User Programmable Word
|
LED Alarm Indicators
|
Signal Loss, AIS, Frame Loss, MFrame Loss, Pattern Loss, Remote Alarm, Error, Clock Slip.
|
Error Injection
|
Type: BIT, FAS, CRC4, CODE, E-BIT
|
Single, Fixed Rate : 10 -2 , 10 -3 , 10 -4 , 10 -5 , 10 -6 , 10 -7
|
Performance Analysis
|
ITU-T G.821, G.826 and M.2100
|
Display
|
320x240 pixel backlit monochromatic LCD
|
Serial Port
|
RS-232C
|
Rechargeable Batteries
|
5×1.2V AA NiMH batteries, continuous working for 6 hours
|
Recharge Time
|
Approx. 2 hours
|
AC Power Adapter
|
Input: 100V ~ 240VAC, 50/60Hz Output: 12VDC/1.5A
|
TestManager Pro
|
WIN98/ME/NT/2000/XP
|
Dimensions
|
L×W×H 200mm × 160mm × 45mm
|
Operating Temperature
|
0°C ~ 50°C
|
Storage Temperature
|
-20°C ~ 70°C
|
Humidity
|
5% ~ 95% non-condensing
|
