Price: | Negotiable |
---|---|
Trade Terms: | FOB |
Min Order: | 1/Piece |
Pay Type: | L/C,T/T |
Model |
RCGF16126 | RCGF18186 | RCGF24248 | RCGF32328 | RCGF404012 | RCGF505012 |
Heads of washing, filling, sealing |
16-12-6 | 18-18-6 | 24-24-8 | 32-32-8 | 40-40-12 | 50-50-12 |
Production capacity |
3000-4000BPH | 5000-7000 | 8000-12000 | 12000-15000 | 16000-18000 | 20000-24000 |
Suitable bottle diameter |
Φ=50-100mm, H=170mm, 330-2500ml | Φ=50-100mm, H=170mm, 330-2500ml | Φ=50-100mm, H=170mm, 330-2500ml | Φ=50-100mm, H=170mm, 330-2500ml | Φ=50-100mm, H=170mm, 330-2500ml | Φ=50-100mm, H=170mm, 330-2500ml |
Spraying pressure |
0.2-0.25Mpa | 0.2-0.25Mpa | 0.2-0.25Mpa | 0.2-0.25Mpa | 0.2-0.25Mpa | 0.2-0.25Mpa |
Filling temperature |
85-90°C | 85-90°C | 85-90°C | 85-90°C | 85-90°C | 85-90°C |
Filling type |
Hot filling | |||||
Motor power |
2..2+0.37kw | 2.2+0.37kw | 3+0.45kw | 5.5kw | 7.5kw | 11kw |
Stainless steel |
SS304 | SS304 | SS304 | SS304 | SS304 | SS304 |
Electric voltage |
380V50Hz | 380V50Hz | 380V50Hz | 380V50Hz | 380V50Hz | 380V50Hz |
PLC |
Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi |
Frequency converters |
Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi |
Touch screen |
Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi | Mitsubishi |
Circuit contactor |
Siemens | Siemens | Siemens | Siemens | Siemens | Siemens |
overall dimension |
2400*1600*2500 |
2500*1800*2500 |
3100*2300*2800 |
3800*2800*2900 |
4600*2800*2900 | 54500*3300*2900 |
Weight |
2500kg | 3500kg | 4500kg | 6500kg | 8500kg | 9800kg |
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
---|---|
Station: | Full-Automatic |
Production Capacity: | 2000-4000b/H |
Material: | Stainless Steel 304 |
Temperature Range: | 60-100 |
Bottle Material: | PVC /Pet/PP |
Bottle Size: | 200ml-2000ml |
Quality Certificate: | CE ISO: 9001 |
Structure: | Washing/Filling/Capping Integrated |
Power: | 5.03kw |
Usage: | Inner |
Packaging Containers: | Bottle |
Operational Method: | Filling |
Product Type: | Daily Use |
Product State: | Liquid |
Type: | Washing Filling and Sealing |
