Features:
1) Three step roller, four side sealing, both fast and stable, low noise, but seals firmly, reliably airtight, with bags coming smoothly, packs efficiently
2) Horizontal stroke pump is used to fill, matches with special feeding nozzle
3) An imported frequency changer is used for stepless speed adjusting, an intelligent temperature control regulates the sealing temperature. It performs reliably, and is convenient to operate
4) Photoelectric tracking system is used to ensure the automatic correcting of double faced printing designs on the packing bags, precise counting
5) Liquid crystal touch screen display is used to allow for a graphical user interface
6) It can do stepless adjustment for pouch length and width suitable for packing medium dosages
7) It is applicable to a wide range of uses, and is suitable for all complex film packing materials
Usage:
It is suitable for paste substances including cream, ketchup, peanut butter, and catsup in the pharmacy, food and daily use chemica lindustries.
Bag length | 50-250mm(L) adjustable |
Bag width | 36-140mm(W)( if change width, should change bag mould) |
Packing speed | 30-50 bags/min depend on punch size and material |
Measuring range | 2-120ml/bag |
Cutting fashion | Flat cutting, with tear notch |
Sealing fashion | 4 side sealing |
Applicable film | PET/AL/PE PET/PE NY/AL/PE NY/PE/aluminize/complex film |
Max width of film roll | 350mm |
Max film roll diameter | Φ 300mm |
Film roll core diameter | Φ 70-76 mm |
Power voltage | 220V/ single phase 50HZ |
Power | 5.5KW |
Machine Dimension | (L)1800mm× (W)1000mm× (H)2200mm |
Deadweight of machine | 650KG |
Ruian Medium Pack international trading Co., Ltd is an import & Export company of Ruian Sanyang Technology Factory. We located in Ruian city, Wenzhou, zhejiang, China. We possess very convenient traffic conditions as our company, just need 1 hour from Shanghai to Wenzhou by air.
Our company is a national high-tech enterprise, China pharmaceutical equipment industry association member units, the pharmaceuticals Vice President unit of food machinery industry association of Wenzhou. And has passed the ISO9001 quality management system certification and the EU CE product safety certification.
Now as the country's leading professional manufacturer of pharmaceutical machinery, food machinery, we pursue technology and production of highly uniform, advocating the premier of quality and service, with great boldness and become a shining star of China's packaging industry.
Company has standard workshops and advanced production equipments, a well-trained professional technical team, beyond the new concept of the EGO, integrates with enterprise, quality awareness and improve the quality assurance system all throughout each production link of the enterprise.
Company production' ZHONGBAO' Brand DXD series automatic filling packaging machine, was introduction, digestion and absorption, the combination of innovation and independent development and research into a new generation of leading domestic level of packaging machinery. Suitable for pharmaceutical, food and daily chemical filed. Can automatic fill and packaging tablets, capsules, viscous, liquid, granules, powders and other materials. Multiple products by Zhejiang Provincial electromechanical product quality testing of the detection and identification of new products and technologies at the provincial level, and won a number of scientific and technological progress awards and several national invention patents, utility model and design patents.
Company's sales network, cross the world, some products are sold throughout the country and exported to Asia, Africa and Europe, more than 30 countries and regions. International customers as: MACDONALD, PT. SAYAP MAS UTAMA from Indonesia, SARL SPOCAA from Algeria, ICEEPAK Australia
We think employees are the Foundation of the fundamental, company of each a times progress are originated from each employees tireless of efforts and obsession of pursuit, to share of sincere, together growing up with employees and society, share success.
