Product Specifications
| Prod Model: |
TRS4-C |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Products: |
Trs4-C |
| Rated Operating Voltage Un: |
220V |
| Max Continuous Operating Voltage Uc: |
385V |
| Nominal Discharge Current In: |
20ka |
| Max Discharge Current Imax: |
40ka |
| Residual Voltage Up: |
1.8kv |
| Temperature: |
-40c- +70c |
| Structure: |
Protective Gap |
| Package Size: |
385mm*210mm*220mm. |
| Type: |
Power Source Arrester |
| Classification: |
Surge Protection Device |
| Installation: |
Standard Guide Card Installed |
| Brand: |
Thor |
Product Description
Application Scope and Installation Position
TRS-C Series surge protective device suitable for the new energy wind power generation system,its working voltage covers 500V,800V and 1000V.It is installed in the main power system at DC circuit,to protect against the indirect lighting current,direct lighting current or other instantaneous over voltage.
Product Features
1.Plug in/out style protective device.
2.The coler of visible window shows operating status.
3.Double protection of over-heat and over-current.
4.Have the accessory of remote signaling interface,could be remote control.
Technical Parameters
Type | TRS4-C |
Rated operating voltage Un | 220v |
Max continuous operating voltage Uc | 385V |
Nominal Discharge Current In(8/20μS) | 20kA |
Max Discharge Current Imax(8/20μS) | 40kA |
Residual Voltage Up | 1.8kV |
Response Time ns | ≤25ns |
Operating Condition | Temp-40ºC- +70ºC RH≤95%(25ºC) Sea level elevation≤3km |
Installation | Standard guide card loaded |
Zhejiang Thor Electric Co., Ltd. is a professional enterprise specialized in producing surge protectors. Our company is located in Liushi.
Our company currently provides up to 60 kinds of surge protectors. We also provide surge protectors according to customers' requirements.
With strict management, standardized production workshops, advanced ERP management system, efficient workers, and professional technical personnel, we are providing customers with high quality and cheap products.
We welcome the friends from all over the world to negotiate with us for the cooperation and development of lightning over-voltage protection market.
Our goals: To become a professional company of designing and manufacturing over-voltage protection products and lightning products.
Business:
Full range of mine supply
Lightning Products spare parts supply
Behalf of the delivery of product testing testing organizations
Lightning Products invites agents around
Product mold design and manufacturing
Quality assurance:
ISO 9001 Quality Management System Certification
CE and RoHS certification
Lightning protection device by Beijing Testing Center
Lightning protection device by Shanghai Testing Center
Product sold five-year warranty
