Product Specifications
| Prod Model: |
MVT-6004D |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Compression: |
H.264 |
| Record And Playback Frame: |
4*25fps@D1(PAL), 4*30fps@D1(NTSC) |
| Network Function: |
Yes, Support Remote View Via Computer and Mobile |
| Hard Disk: |
Without HDD, But Support 1PC Max 2000GB SATA HDD |
| Advantage 1: |
No Setting for DDNS and Port Forwarding |
| Advantage 2: |
4CH DVR Support Showing Customers Turn on Logo |
| Advantage 3: |
with Free DDNS Sever |
| Advantage 4: |
Digital Zoom Function to View More Details |
| Advantage 5: |
HD VGA(1280*1024) Output |
| With Alarm Funciton: |
Yes |
| Type: |
Standalone |
| Video Compression: |
H.264 |
| Compressed Format: |
H.264 |
| Operating System: |
Linux |
| Application: |
Commercial DVR |
| Interface Type: |
BNC/VGA/HDIM |
| Video Input/Output: |
4 Channel |
| Audio Input/Output: |
4 Channel |
| Remote Control: |
With Remote Control |
Product Description
4CH Full D1 P2P DVR With Free DDNS(MVT-6004)
What is the superior feature of the DVR?
L H. 264 compression format
L P2P/NAT function
L D1 display resolution
L support Audio&Alarm input and output, PTZ control
L support 1PCS SATA
L support remote controller and remote view
How to use P2P view via PC and Mobile Phone
1. Get the icloud, Main menu→System Upgrade
2. Download the QMeye APP&Manual
3. Install the APP
4. Enter into management and add the device
5. Enter the Live view
P2P advantages: No need of stable IP address! ! No need of DDNS setup! ! No need of Router setup! ! ! Reducing your after-sales cost!
Let's test a SAMPLE!
Selling points for MVTEAM DVR
1) support P2P function via IE, QMEYE CMS in PC and iPhone & Andriod mobile phone.
It will be much easier(without port forwarding) for remote access than traditional DDNS.
2) QMEYE software can support record the video in mobile phone and remote playback the recorded video in DVR. This is the new function for the DVR in 2014.
Our company introduction:
MVTEAM is a professional manufacturing & exporting company specialized in the surveillance equipments including Megapixel IP Camera, HDSDI Camera, HDCVI Camera, CCTV camera, PTZ camera, Standalone DVR, DVR Kit, Video Balun, CCTV Tester and Related Accessories. With more than 10 years experience in the security equipment we are able to supply high quality one-stop security service. Welcome to deal business with us. Your best satisfaction is our greatest success!
MVTEAM Services:
1. Good Reply. Your inquiry related to our products or price will be replied within 24 hours.
(except Statutory holiday in China)
2. OEM&ODM. Any your idea on camera we can help to design and put it into products.
3. Warranty. 1 years since delivered out
4. Technical Support. Before sale and after sale
5. Lead time. 5-7 business days
6. Humane management policy. We will keep the overpaid or lesspaid shippingcost & intermediary bank charge into next new order.
| Model | MVT-6004D |
| System | Main Processor | High performance embedded microprocessor |
| Operating System | Embedded LINUX |
| System Resources | Pentaplex function: Live, Recording, Playback, Backup & Remote access |
| Control mode | Front panel, USB mouse, IR remote control, keyboard, network |
| Video | Input | 4 channel, BNC(1.0Vp-p,75Ω) |
| Output | 1TV, BNC(1.0Vp-p,75Ω),1VGA |
| Audio | Input | 4 channel, BNC(200-2800mv, 30KΩ) |
| Output | 1 channel, BNC(200-3000mv, 5KΩ) |
| Display | Display Split | 1, 4ch |
| Resolution | 1024 x 768, 800 x 600 |
| Tour display | Support |
| OSD | Camera title, time, video loss, motion detection, recording |
| Digital zoom | support digital zoom function while display and playback |
| Record | Image Resolution | 960H(704x576) |
| Encoding Speed | Main Stream:D1(1~25/30F/S) |
| Extra stream: QCIF(1~25/30fps) |
| Image Quality | 1~6level(level 6 is the best, VBR effectively) |
| Recording Mode | Manual, schedule(regular(continuous),MD(Video detection: Motion detection, camera blank, Video loss),Alarm),Stop |
| Recording priority | Manual>Alarm>Motion detection>Regular |
| Video Detection | Trigger Events | Recording, PTZ movement, Alarm, E-mail |
| Motion Detection | Zones:396(22x18),sensitivity:1-5(level 5is highest) |
| Alarm | Video Loss | Support |
| Alarm Input/Output | 4 channel in/1channel out |
| Playback | Playback Channel | 1, 4ch |
| Playback Speed | D1(1~25/30FPS/CH) |
| backup | Search Mode | Time/Date, Alarm, Motion Detection |
| Backup Mode | Flash drive/USB HDD/USB CD/DVD-RW/Network download |
| Network | P2P funtion | No setting for DDNS and port forwarding when IE browser remote view |
| Network Functions | TCP/IP, UDP, DHCP,DNS, IP Filter, PPPOE, Email, Alarm Server, uPNP |
| Remote Operation | Monitor, PTZ control, Playback, System setting, File download, Log information |
| Hard Disk | Hard Disk | 1SATA port,Max2TB HDD supported |
| Space occupation | Audio:28.8MB/H, Video:56~900MB/H |
| HDD Management | Hard disk hibernation technology, HDD faulty alarm |
| Auxiliary Interface | USB Interface | 3 USB ports,for mouse control,backup |
| RS485 | PTZ control |
| Environment | Power Supply | AC 100~240V,50/60Hz |
| Power Consumption | 25W |
| Working Environment | -10°C~+55°C/10~90%RH/86~106kpa |
| Dimension | 340(L)*265(W)*70(H)mm |
| Weight | 3.2KG |
