Product Specifications
| Prod Model: |
(4pg1618) |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Rotor Diameter: |
1600mm |
| Rotor Length: |
1800mm |
| Capacity: |
80-650t/H |
| Number Of Rolls: |
4 |
| Drive Mode: |
Belt or Coupling |
| Type: |
Roller Crusher |
| Motor Type: |
AC Motor |
| Condition: |
New |
| Application: |
Electrict Power,Mining,Coal,Chemical and So on |
| Outlet Size: |
0.1-50mm |
| Inlet Size: |
<90mm |
Product Description
Outline:
Four roller crusher with high efficiency, energy saving, intelligent and so on. Mainly applied compressive strength values ≤ 200MPa, particle size ≤100mm material, such as limestone, coal gangue, ceramic raw materials, coke, etc. Broken, directly crushed to less than 1mm (90%). It has acrushing large capacity unit, small energy consumption, widely used and so on. Mainly used in electric power, mining, coal, chemical and other industrial sectors, is crushing industry one of the best.
Features:
1. High yield, uniform particle size, particle size of 0.1 ~ 5mm range crushing adjustable.
2. Two rolls of air swirl basic offset each other, equipment import and export of wind pressure is extremely Small, basic does not generate dust, do not install a dedicated dust removal equipment.
3. Using a special movement principle, the device does not block non-stick, no requirement for crushing material moisture.
4. A significant reduction in vibration and noise (no damping platform), dynamic load is only 1.3 times the static load of the building has little effect.
5. Includes a special opening device can easily open the device's doors for easy access to replacement of wearing parts.
The main technical parameters:
Model | Rotor diameter
(mm) | Rotor length
(r/mm) | Maximum
Feed size (mm) | Discharge size (mm) | Capacity (t/h) | Number of rollers | Motor power (kw) | Drive mode |
| 4PG0404 | 400 | 400 | <20 | 0.1-10 | 2-30 | 4 | 7.5(11) |
Belt or coupling |
| 4PG0605 | 6 0 0 | 500 | <40 | 0.1-16 | 5-55 | 4 | 22(30) |
| 4PG0806 | 800 | 6 00 | <40 | 0.1-22 | 8-85 | 4 | 30(37) |
| 4PG0709 | 700 | 900 | <55 | 0.1-22 | 12-115 | 4 | 37(75) |
| 4PG1009 | 1000 | 900 | < 65 | 0.1-25 | 18-180 | 4 | 55(75) |
| 4PG1210 | 1200 | 1000 | <85 | 0.1-30 | 30-230 | 4 | 75(90) |
| 4PG1216 |
|
|
|
| 50-380 | 4 | 90(110) |
| 4PG1618 |
|
|
|
|
|
|
|
