Product Specifications
| Prod Model: |
FCPCB064A |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Solder Mask: |
Green |
| Silk Screen: |
White |
| PCB Thickness: |
1.6mm |
| Type: |
Rigid Circuit Board |
| Dielectric: |
FR-4 |
| Material: |
Fiberglass Epoxy Resin + Polyimide Resin |
| Flame Retardant Properties: |
V0 |
Product Description
OEM/ODM/EMS Services for PCBA:
- PCBA, PCB Board assembly: SMT & PTH & BGA
- PCBA and enclosure design
- Components sourcing and purchasing
- Quick prototyping
- Plastic injection molding
- Metal sheet stamping
- Final assembly
- Test: AOI, In-Circuit Test (ICT), Functional Test (FCT)
- Custom clearance for material importing and product exporting
Capability - SMT
- Lines 9(5 Yamaha,4KME)
- Capacity 52 million placements per month
- Max Board Size 457*356mm.(18"X14")
- Min Component size 0201-54 sq.mm.(0.084 sq.inch),long connector,CSP,BGA,QFP
- Speed 0.15 sec/chip,0.7 sec/QFP
Capability - PTH
- Lines 2
- Max board width 400 mm
- Type Dual wave
- Pbs status Lead-free line support
- Max temp 399 degree C
- Spray flux add-on
- Pre-heat 3
Technical Data:
Stencil size/range:
736x736mm
Maximum PCB size:
1200x 500mm
Minimum PCB thickness:
0.35mm
Minimum chip size:
0201 (0.2x0.1)/0603 (0.6 x 0.3mm)
BGA ball pitch:
1.00mm (minimum), 3.00mm (maximum)
BGA ball diameter:
0.40mm (minimum), 1.00mm (maximum)
QFP lead pitch:
0.38mm (minimum), 2.54mm (maximum)
Frequency of stencil cleaning:
1 time/5 to 10 pieces
Turn Times:
Quick turn are our Specialty
Volume:
One piece to low valume production quantityes
Low cost first article builds
Schedule deliveries
Assembly type:
Surface mount(SMT) assembly
Thru-hole
Mixed(surface mount and thu-hole) technology
Single or double sided placement
Cable assembly
Components type:
Passive components:
As small as 0402 package
As small as 0201 with design review
Ball Grid Arrays(BGA):
As small as .5mm pitch
Stencil:
Laser cut stainless steel
Parts procurements:
Turnkey(we supply the parts)
Consigned(you supply the parts)
You supply some parts, we do the rest
Solder type:
Leaded
Lead-free/ROHS compliant
Other capabilities:
Repair/rework services
Mechanical assembly
Box build/electromechanical assembly
Mould and plastic injection.
Fulltronics Corporation Ltd is a manufacturer and exporter specializing in Printed Circuit Board fabrication, Assembly and development from the start of 2002
In the early years our core business consist of fabrication of prototypes pcbs, High frequency pcbs, multilayer pcbs, flex pcbs and rigid-flex pcbs for companies of home and abroad. All PCBs are manufactured with advanced quality control systems and are recognized by ISO-9001 and TS16949, UL Certification and ROSH. In 2006 Fulltronics set up an assembly house enabling us to offer a fully integrated array of services, including SMT Assembly, T/H Through Hole Assembly, wire Assembly, Box-build&assembly and functional testing to ensure the highest level of quality control. You can choose any of the procedure you need.
Today our products are applied for medical, defence, broadcasting, telecommunication systems, Industrial control, traffic intelligence systems, auto industry, agriculture and so on. We manufactured products keeping high pace with newly technology developments. Fulltronics Corporation combines fashion and application well to satisfy diverse of customers requirments.
For the most, we take pride in providing excellent quality Products at very competitive prices, outstanding service and timely delivery. If you have any PCB or PCB Assembly projects, just give us opportunities, we perfect your ideas.
