Product Specifications
| Prod Model: |
MS8250D |
| Markets: |
North America,South America,Eastern Europe,Western Europe |
| Grade: |
Professional |
| LCD Display: |
4000 Counts |
| Diode: |
2.7V |
| Display Mode: |
Digital |
| Power Source: |
AC and DC |
| Theory: |
Electronic Meter |
| Installation: |
Portable |
Product Description
Digital Multimeter MS8250D
Features of Digital Multimeter MS8250D
* Display: 6600 counts
* Auto Ranging: yes
* Manual Ranging: yes
* REL: Relative measurement
* True RMS: true root mean square measurement
* NCV: Non-contact voltage detector
* Didoe: 2.7V
* Continuity Buzzer: <50Ω
* Max/Min: yes
* Data hold: yes
* APO: auto power off
* LBD: low battery display
* Display backlight: yes
* USB interface: windows OS
Specifications of Digital Multimeter MS8250D
* DC Voltage
- Range: 660mV/6.6V/66V/600V; Accuracy: +/-(0.5%+2)
* AC Voltage
- Range: 660mV/6.6V/66V/600V; Accuracy:+/-(1.0%+2)
* DC Current
- Range: 660μA/6600μA/66mA/660mA; Accuracy:+/-(0.8%+2)
- Range: 10A; Accuracy: +/-(2.0%+2)
* AC Current
- Range: 660μA/6600μA/66mA/660mA; Accuracy:+/-(1.2%+2)
- Range: 10A; Accuracy: +/-(3.0%+2)
* Resistance
- Range: 660Ω/6.6KΩ/66KΩ/660KΩ/6.6MΩ/66MΩ; Accuracy:+/-(0.8%+2)
* Capacitance
- Range: 6.6nF/66nF/660nF/66μF/660μF/66mF/660mF; Accuracy: +/-(4%+5)
* Frequency
- Range: 0~66MHz; Accuracy: +/-(0.3%+2)
* Duty cycle
- Range: 5%~95%; Accuracy: +/-(2%+2)
* Power supply: 1x9V 6F22 battery
* Product size: 175mm x 86mm x 52mm /6.89" x 3.38" x 2.04"
* Product weight: 350g/0.8lb
* Safety rating: CE CAT IV 600V RoHS
