BROATEK diesel engines adopt spherical combustion chamber and dry type cylinder linder.
It has the feature of compact construction, high generalization of parts, less fuel consumption, low noise and convenient operation and maintenance.
G Series Stationary power Unit is a version of Model 495Bgiesel Engine which has continually Award the. National Golden Medal prize thrice, Manufactured with advanced technology and reliable quality, and has good reputation both in domestic and worldwide market.
G Series Stationary power Unit has wide applications; easy to operation and can be used for drainage, irrigation, prawn breeding, brick making, farm by-product processing, etc.
For the convenience of customers, our corporation also produces Cb500 Diesel Engine Water Pump unit, consists of 495BG diesel engine and 8HB-35 mixed flow pump, 500m3/h capacity,12.2m head, 1600r/min, and 4m allowable suction head. It is and ideal machine, for drainage and field irrigation.
495BG produced by our corporation also can be matched with 6JD56×10 deep well pump, up to 563/h flow capacity,80m head, and 2940r/min speed.
Selection of model and negotiations are welcome.
Specification
| Model | BR395BG | BR495BG | BR4100BG | BR4102G |
| type | Water cooling,4-cycle, vertical, in-line, spherical combustion chamber,left |
| Cylinder x diameter x strokes | 3×95×115 | 4×95×115 | 4×100×115 | 4×102×115 |
| Rated Power(KW) | 26.5 | 35.3 | 43 | 44 |
| Rated speed(r/min) | 2000 | 2000 | 2000 | 2000 |
| Compression ratio | 16.5:1 | 16.5:1 | 17.5:1 | 17.5:1 |
| Method of starting | 12V electric starting |
| Net weight(kg) | 480 | 510 | 510 | 510 |
Remark:
BR395BG--B Type 4-Groove pulley is available.
BR495BG--C Type 6-Groove pulley is available.
