Using industrial-grade embedded platform, the system is stable and reliable, it has rich interfaces.
Wireless communication, GPS navigation, fault detection, video acquisition and other functions, extensible to provide users with a powerful vehicle-mounted mobile multimedia information systems.
It can be widely used in personal entertainment, emergency command, transportation scheduling, mobile office, multimedia advertising, industrial control and other fields.
- Comply with IP64 Standard, dust & water-proof;
- High-speed Freescale CPU inside;
- Wide power voltage 9-36V;
- Keyboard or Mouse supports;
- Strong vibration resistance;
- USB Host 2.0×1, USB Device 2.0×1
- RS232×4 / RS232×3, RS485×1 / RS232×2, RS422×1, RS485×1;
- GPIO input×4, GPIO output×6;
- Optional: GPS (external), Camera 5.0M (built-in), Bluetooth & Wi-Fi 802.11 b/g/n (built-in), 3G (built-in), CAN×2, Battery 2200mA (built-in).
Display Screen 7" LED backlit
Resolution 800×480 (1,152,000 pixels)
Touch Panel Capacitive
Brightness 450cd/m2
Aspect Ratio 16:9
OS Windows CE 7.0 / Android 2.3.4 / Linux 2.6.35
CPU Freescale iMX.53x 800MHz / 1.0GHz
Core ARM Cortex-A8
Memory 512MB DDR3 RAM + 4GB NAND FLASH
Expansion Storage Micro SD (TF) card
LAN Ethernet 10/100M (RJ45)
Transfer Interface USB Host 2.0×1, USB Device 2.0×1
RS232×4 / RS232×3, RS485×1 / RS232×2, RS422×1, RS485×1
GPIO input×4, GPIO output×6
Audio Ear phone slot ×1
Speaker (front) ×1
Speaker 1W
Power consumption: 9W
Working Temperature: -10 - 65ºC
Storage Temperature: -25 - 80ºC
Power Supply: DC 9-36V
Dimension(LWD): 200 ×128 × 36 mm
| Accessories: |
| Extended cable: 1 Piece |
| Driver disk: 1 Piece |
| Power adapter: 1 Piece |
| Operation manual: 1 Copy |
| VESA 75mm rail slot (optional) :1 Piece |
