90HP 4WD Farm Front Loader for Tractor Price List
| Price: |
US $ 16000/Piece |
| Trade Terms: |
FOB,CFR,CIF |
| Min Order: |
1/Piece |
| Pay Type: |
L/C,T/T |
Agricutural wheel tractor 904
*4*4 wheel drive
*Dual clutch
*Cabin with warmer
Specification
Parameters
Model 904
Type 4WD Wheeled Type
Length 3700mm
Width 2100mm
Height (up to the top silencer) 2700mm
Wheel base 2195mm
Rear Wheel Tread 1520mm
Axle Base 2316mm
Min. Ground Clearance
379mm(front drive axle under)
Structure weight with cabin 3820kg
Front ballast 250
Rear ballast 170kg, 340kg, 510kg, (optional)
Rated traction force 20.8KN
Engine Model YTO
Engine Type 4-Cylinder
Cooler typer Water
Stroke 4 Stroke
Rated Power 66.2 +/-5%/12h
Rated Speed 66.2/2300kw/r/min
Maximum torque/speed(N. M(r/min)
380+/-5%/1500-1700
Mini speed 750+/-30
Fuel Diesel
Front Wheel Tyre 8.3-24
Rear Wheel Tyre 14.9-30
Clutch Dual-stage clutch
Steering Power steering
Transmission Type 8+2 or (8+2)× 2 with creeper shift
Suspension Type 3-point links
Type and Rev Semi-independent Type 540/1000
Spline Size F35 Rectangle Spline with 6 teeth
Model |
Map904 |
Drive type |
4x4 |
Engine |
Engine model |
LR4M5-23, YTO, diesel engine, 4 cylinder,in-line, direct injection |
Capacity of fuel tank(L) |
150 |
Rated speed (r/min) |
2300 |
Engine power (kw) |
66.2 |
Lowest fuel consumption (g/kw·h) |
≤242 |
Transmission |
Clutch |
Dry,dual-stage type |
PTO Speed(rpm) |
540/1000 or 760/1000(optional) |
Gearshift |
8F+4R |
Three point linkage |
Category of 3-point link |
Rear,Cagetory II |
Lifting capacity(at point
of 610mm)KN 610mm |
>16 |
Technical parameter |
Dimension(with cabin) LxWxH mm |
3700x2250x2700 |
Dimension(without cabin) LxWxH mm |
3700x2250x2100 |
Wheel base(mm) |
2195 |
Track base(mm) front wheel |
1610 |
Track base(mm) rear wheel |
1620-2020(usual 1620) |
The smallest clearance(mm) |
379 |
Front tyre |
11.2-24 |
Rear tyre |
16.9-34 |
| Prod Model: |
MAP904 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Tractor: |
with Front Loader |
| Rated Power: |
110HP |
| Attached Implements: |
Front Loader, Backhoe Loader, Rotary Tiller |
| Cabin: |
with Warmer |
| Front Tire: |
11.2-24 |
| Rear Tire: |
16.9-34 |
| Type: |
Wheel Tractor |
| Usage: |
Farm Tractor |
| Certification: |
EPA |
| Drive Wheel: |
4WD |
| Fuel: |
Gas / Diesel |
| Condition: |
New |
| Emission Standard: |
China National II |
| Color: |
Blue or Red |
Weifang Map Power Co., Ltd., was founded in 2006. We are a professional manufacture and chain supplier specializing in construction machinery and agricultural equipments. 70% of our products are made for export.
We keep diverse products according to customer and market demand. We produce and supply site dumpers, wheel loaders, tractors, implements, wheel excavators, crawler excavators, backhoe loaders, forklifts, road rollers, light towers, concrete mixers, plate compactor, impact tampers, road cutters, concrete vibrators, and so on.
With experiences in professional manufacturing, Map Power has successfully sold equipments to around 30 countries and areas around the world including Australia, New Zealand, Canada, England, Poland, Dutch, Italy, Russia, India, Main countries of Africa...
Our main products list.
Agricultural machinery:
1. Tractor from 18HO-130HP
2. Farm implemants covered dics mower, lawn mower, tractor mouting front end loader, backhoe loader, sweeping machine, snow blower, dics plow, dics harrow and etc.
Construction machine:
Wheel Loader, Truct Crane, Wheel Excavator, Crawler excavator, Backhoe Loader, Forklift, Road Roller, Concrete Mixer, Plate Compactor, Impact Tampers, Road Cutters, Concrete Vibrators, and so on.
Customer's requirement is our first priority. We can provide reliable, fast and professional service for you through telephone, on-site or network channels. We are ready to provide all customers with 10 years spare parts supply. Furthermore, if your products parts are damaged, please also contact us to see if it could be restored, and if so, you can avoid the trouble and cost of purchasing new spare parts. In our spare parts department, customers can get professional technical advice, as well as the relevant information regarding all products and services
With experiences in professional manufacturing for more than 10 years. WEIFANG MAP POWER Co. Has successfully sold equipments to around 40 countries and areas. We sincerely welcome customers and friends all over the world to visit our factory and cooperate with us in the future.
