Product Specifications
| Prod Model: |
3600mm |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Process: |
Paper Machine |
| Usage: |
Paper Machine |
| Automatic Grade: |
Automatic |
| Computerized: |
Yes |
| Type: |
Machine |
| Certification: |
ISO |
Product Description
Technical data
Out put paper: Writing paper, print paper, copy paper;
Gram weight: 80-100G/M2
Net width: 3600mm
Rail gauge: 4600mm
Working speed: 250m/min
Capacity: 80--100T/D
Drives: AC frequency conversion speed regulator. Processing transmission
Our A4 paper machine is the best choice among the manufactures that produce medium or high level products. This A4 paper machine is suitable for cutting the large coil packaging material(such as Gloss photo paper, digital photo paper, ordinary paper, coated paper, board paper, Gold or Silver cardboard, holographic paper, cigarettes & wines packing and printing material. Etc), paper & plastic complex material and fiber material, etc.
2. Features of A4 Paper Machine
This A4 paper machine adopts the servo motor to control the fixed-length cutting, feeding. A4 Paper machine is equipped with the photoelectric, Correction, tracing modifying system. Our A4 paper machine can do crosscutting and Vertical cutting at the same time. And it can trace feeding institution with the products, blowing& absorbing transportation at same time, automatic collecting, and Robert automatic folding materials and cross transport to worktable.
Drive System of our A4 paper machine use pneumatic system, photoelectric sensor to control, and folding materials system use air and oil pressure to improve equipment. This A4 paper machine integrates photoelectric, liquid and gas as a whole, PLC touching screen, and has the features of easy operation, high-precision cutting, state operation and low noise.
The A4 paper machine has the feature of the motor frequency speed adjustment, automation counting, giving an alarm when stop and tension with digital indication.
All transitional rollers can be done in client's opinions to avoid surface injure.
This A4 paper machine is very important to Scratch of Gloss photo paper.
We designed the air compress transport system for the A4 paper machine.
|
Number |
Equipment |
Qty |
|
1 |
3200mm fourdrinier and multi-cylinder
cultural paper making machine |
1 set |
|
2 |
3200mm winding machine |
1 set |
|
3 |
3200mm rewinding machine |
1 set |
|
4 |
3200mm calender |
1 set |
|
5 |
Pulp washing machine |
2sets |
|
6 |
Pulp pump(6″ ) |
14 sets |
|
7 |
Pulp pump(8″ ) |
22 sets |
|
8 |
Vertical pressure screen |
4 sets |
|
9 |
450 Double disks refiner |
4 sets |
|
10 |
Decker thickener |
4 sets |
|
11 |
Sand cleaner |
24 (4groups) |
|
12 |
10m 3 high consistency hydrapulper |
2 sets |
|
13 |
The whole set of work bench |
1 set |
|
14 |
1000Thruster |
12 sets |
Our company has over 420 employees. There are five factories in China with the total area of 20, 000m2, it has passed the ISO14001 international authentication
Our products include paper making machines, parts and paper processing machines such as kraft paper machine, tissue paper machine, cultural paper machine, fiber separator, hydrapulper, rewinder, napkin folder, tisue slitter and ao on. They have been exported to more than 8countries and regions, such as America, Russia, Brazil, Indonesia, Fiji, etc. Relying in perfect & advanced technology, sincere service and inexpensive products with high quality, we have won the recognition of international market and clients
Why choose us
Our company gathers a technique team of engineers and experts with over 30 years' experience which helps us be a professionall on all kinds of paper making machines and make us competitive on the market. We focus on quality and customers' need and improve our technology and service continually. We believe our devotion to work will help us to achieve global leadership in providing first-class products and superior quality services to customers around the world
Our advantages
Technical advantage
1. Experiences producing team
2. Advanced technological strength
Product advantage
1. Through the international authentication
2. Same material with most preferential price
3. A lot of varieties for the customer to choose
Service advantages
1. Technical consultation
2. Project evaluation
3. Detailed design of factory
4. Installation and test the whole production line
5. Training engineers and workers
6. Supplying spare parts for long time
