Quick Details
Place of Origin: Zhejiang, China (Mainland)
Brand Name: ZOFR
Model Number: SSR
Theory: Solid State Relay
Usage: General Purpose
Size: 62L*45W*23.5H
Protect Feature: Epoxy
Contact Load: High Power
Packaging & Delivery
Packaging Details: Standard export packing
Delivery Detail: 11~15 Days
Specifications
SSR-relay
Load Current: 10A, 15A, 20A, 25A, 30A, 40A, 50A, 60A, 80A
Load Voltage: 5-60VAC
Control Voltage: 3-32VDC
SSR relay
Technical Data
Load Current: 10A, 15A, 20A, 25A, 30A, 40A, 50A, 60A, 80A
Load Voltage: 5-60VAC
Control Voltage: 3-32VDC
Control Current: DC 5-25mA
On voltage ≤ 2.3V
Off Leakage Current ≤ 2mA
On-off Time ≤ 10mS
Dielectric Strength: 2000VAC
Insulation Resistance: 500MΩ /500VDC
Ambient Temperature: -30 ~ +70° C
The working Instructions: LED
Weight: 90~135g
Zhejiang Zhongji Technology Co., Ltd was established in 1991, with advanced technology, our company is equipped with high standard production lines and a stable technical staff, management team for production and examination.
We have more than 100 series and 1, 000 different kinds of relay specifications, and mainly manufacturer all types of electromagnetic relay, PCB relay, auto relay, high power relay, time relay, counting relay, microcomputer control switch, floatless relay, electromotor protection relay, power-saving control switch, solid state relay, static-stated electric relay, gas relay, the relay bases and so on.
The products of our company have been approved by CE, ISO9001, and the China Compulsory Certification (CCC).All of the products have been listed in quality control system in the China Product Quality Association ( CPQA) "21315".We have established many sales branch offices in the domestic market, and the products are well sold and highly praised in more than 30 provinces, cities and municipalities, and as far away in Europe, America, Southeast Asia, Middle East and Africa, etc.
Zhejiang Zhongji Technology Co., Ltd.With advanced technology, superior quality, reasonable price, good reputation, warm and thoughtful service, provides products to customers' satisfaction.We are willing to sincerely cooperation, create brilliance!
