Product Specifications
| Prod Model: |
WH-E19 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Printing Method: |
Direct Thermal Line Printing |
| Paper Out Detection: |
Paper End Sensors Function |
| Paper Loading Way: |
Easy Paper Loading |
| Paper Width: |
80 Mm |
| Print Width: |
72mm |
| Resolution Ratio: |
8 Dots/Mm(576 Dots/Line) |
| Print Speed: |
60mm/S |
| Installation Dimension: |
100mm*75mm |
| Life Of Printing Head: |
50 Km |
| Input Power: |
DC 9-24V, 30W |
| Interface Type: |
USB |
| Usage: |
Acars Printer |
| Style: |
Black and White |
| Type: |
Acars Thermal Printer |
| Max. Paper Size: |
80mm |
Product Description
BRIGHTEK Profile
Beijing Bright Technology Development Co, Ltd. was established in 1998. It is a high technology firm which is specializing in researching, designing, producing and selling of Micro printer, Programming device, Emluator and interrelated products. The Head office is in Shangdi information industry base(Brilliant International), zhong guan cun Beijing, which located in the key Science and Technology Park. Abut to Baidu in the South, abut to Lenovo in the North. We also have professional direct selling service network in Beijing, Shanghai, Hangzhou, Shenzhen, Guangzhou and other big cities in China. The production capacity of Micro printer is more than 500, 000 per year, and the flexible production capacity could be 1000, 000; The production capacity of programmer and emulator is more than 50, 000. Its overall business scale can rank the industry forefront and fully meet the growing demand for domestic and foreign customers.
Service
We are a manufacturer of mini printer used in bar code printing, cash register, tickets printing and etc. We have rich experience in export this items. So no matter which country you come from, please rest assured that the purchase...
Install
Portable style, POS style installation is simple, some Embedded and Panel style need professional installation, refer to the product installation instructions.
We have design team can provide technical support.
Quality
Each product must go through rigorous testing before delivery to ensure quality.
Certification
IC, LVD, PONY SVHC detection, ISO, Drop test report, SGS
Product Brief introduction
Stylish, delicate and elegant appearance
Very silent printing thru direct thermal printing method
The installation dimension: 100mmx75mm
Paper end sensors and self-motion memory printing function
USB interface, Serial RS-232C, 485, or (serial TTL & Parallel interface)
Add coordinate curve printing function
Abundant figure/curves/characters print function
Easier paper loading
| Item | Specification |
| Printing method | Direct thermal line printing |
| Paper out detection | Paper end sensors function |
| paper loading way | Easy paper loading |
| Paper width | 80± 0.5mm |
| Print width | 72mm |
| resolution ration | 8dot/mm, 576dot/line |
| life of printing head | 50km |
| Printing speed | 60mm/s (when the utilization rate is 25%. ) |
| Character | 6x8dots, 8x16dots, or12x24dots |
| Chinese character library | GB2312, 16x16dots, or24x24dots |
| outline dimension(WxHxD mm) | 106mm*81mm*40.5mm |
| Paper supplied | Thermal roll paper (80mm wide, 30mmø ) |
| Interface | USB/Serial(RS-232C, TTL)/Parallel interface |
| Input Power | DC 9-24V |
| Operating temperature | 5-50 degreeC |
| Storage temperature | -20-60 degree C |
| Operating humidity | 10%-80% |
| Storage humidity | 10%-90% |
Beijing Bright Technology Development Co., Ltd is a leading manufacturer of mini printers for over 16 years. The Company is a high technology firm which was established in 1998, and specializes in research, design, manufacture and sales of mini printers and interrelated products. Now we have many professional direct selling service network in Beijing, Shanghai, Hangzhou, Shenzhen, Guangzhou and other big cities in China.
