Ad22-22 LED Indicator with Buzzer
| Price: |
Negotiable/Piece |
| Trade Terms: |
FOB |
| Min Order: |
500/Piece |
| Pay Type: |
L/C,T/T |
Product Specifications
| Prod Model: |
AD22-22 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Equipment Indicator Lights |
| Light Source: |
LED |
| Input Voltage(V): |
12V DC Fire Indicator |
| Lamp Luminous Flux(Lm): |
8mm Fire Indica |
| Color Temperature(Cct): |
Warm White |
| IP Rating: |
IP65 |
| Emitting Color: |
More |
| Lamp Body Material: |
ABS |
| Place Of Origin: |
Zhejiang, China (Mainl |
| Task: |
Adjust |
| Structure: |
Combination |
| Mathematical Model: |
Linear |
| Signal: |
Continuous |
| Function: |
Automatic Control |
| Certification: |
CE |
| Condition: |
Used |
| Customized: |
Customized |
| Material: |
Plastic |
Product Description
EUROPEAN STANDARD HIGH QUALITY LED PILOT LAMPS with buzzer
AC 110-380V
AC/DC: 6-220V
Standard colour: Red, green and black
Special colour is available
Specifications
1.International Standard: IEC 60947-4-1
2.Gree,Blue,Red,Yellow and others colour
3.CCC,CE,ROHS certificate
4.1 Years Warranty
1.Feature:
Pushbutton and Signal Indicator ( more information, please visit our webste: www.tengen1990.com)
1.International Standard: IEC 60947-4-1
2.Gree,Blue,Red,Yellow and others colour
3.CCC,CE,ROHS certificate
4.2 Years Warranty
2.Specification and Technical:
AD22(LED)series of indicator is equally used LED shining chip as light source with long life, low consumption, small volume and light weight. AD22 indicators are produced by our factory enjoying by lots of clients. In order to fit in with top quality and aesthetic demand of user, we developAD22-22B, C, D, E, G, H, double color lamp, position indicator, shining buzzer and mini short indicator, as well as design shape of AD22-22G/22GS series button and it is possible to meet all kinds of international standard lampshade.
Main technical data:
(1)Voltage of working frequency: 205kV(AC valid calue), 1min.
(2)Insulated resistance≥ 2MΩ
(3)Voltage wave allowed by AC indicator± 20%
(4)Continual working life≥ 30000h
(5)Brightness≥ 60CD/m2
(6)Index of leakage CT1≥ 100
(7)Protection grade is IP40, and it is possible to be made to up to IP67
(8)Using frequency: AC50~60Hz
