Price: | US $ 25/Square Meter |
---|---|
Trade Terms: | FOB,CIF,EXW |
Min Order: | 100/Square Meter |
Pay Type: | L/C,T/T,Paypal |
tion of aerogel thermal insulation panels:
Aerogel thermal insulation panels are made of nano, silica, aerogel compound by special technology. With features of high temperature resistance, low thermal conductivity, easy to install, environmental friendly, waterproof, fireproof, sound insulation and shock absorption etc. The new material is an indispensable high efficiency thermal insulation material in the field of metallurgy, electric power, military, and aerospace etc.
Features of aerogel thermal insulation panels:
1. The thermal insulation effect is 3 to 5 times higher than traditional materials.
2. With 1/2 to 1/5 thickness of traditional material, the aerogel thermal insulation jackets has the same insulation effect of the traditional materials. Heat losing is less, space utilization rate is higher.
3. The unique nano three-dimensional structure of aerogel jackets prevent it from deformation, accumulation and dramatically decreasing of the thermal insulation effect of the traditional material caused by vibration.
4. Good flexibility, tensile and compressive
5. Have excellent waterproof performance. Hydrophobic rate is greater than 99%.
6. Besides thermal insulation and energy saving, the aerogel thermal insulation jackets can absorb sound and buffer vibration.
7. No any the material or component hazardous to human body.
8. Easy to install, remove and replace.
Main Applications of aerogel thermal insulation panels:
1.Medium and high temperature insdustrial furnaces
2.Removale escapecapsule
3.Special military equipments
4.Special shaped insulation cover
5.Integrated insulation system for building and constructions
Physical Properties of aerogel thermal insulation panels:
Datasheet | |
Shape | Roll |
Thickness | 3mm, 6mm, 10mm |
Width | 1500mm |
Thermal conductivity | 0.018w/m.k(at 25°C) |
Maximum Service Temp | 650ºC |
Density | 210kg/m³ |
Water proof | Yes |
Component | nano, silica, aerogel |
Thermal conductivity at different temperature of aerogel fabric | ||||||||||
Tem (ºC) | 200 | -100 | 0 | 100 | 200 | 300 | 400 | 500 | 600 | 650 |
Thermal conductivity (W/(mk)) | 0.090 | 0.011 | 0.013 | 0.019 | 0.021 | 0.024 | 0.030 | 0.036 | 0.042 | 0.048 |
Factory profile
Prod Model: | FMD450 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Thermal Conductivity/ Lamda: | 0.018 W/Mk ASTM C518-10 |
Surface Burning Characteristics: | a En13501 |
Water Vapor Sorption: | 1.1% ASTM C1104/C1104m-13A |
Compressive Resistance: | 60MP |
Surface Treatment: | Full Body Tiles |
Color: | White |
Material: | Silica Aerogel+ Fibre Glass |
Refractoriness: | -50~600 |
Diameter: | 10~70cm |
Apparent Density: | 180~220kg/M³ |
Usage: | Insulation |
