| Price: | US $ 12-13.5/Square Meter |
|---|---|
| Trade Terms: | FOB,CFR,CIF |
| Min Order: | 500/Square Meter |
| Pay Type: | L/C,T/T,D/P,Western Union |
Aluminum Composite Panel for outdoor wall cladding, signboard, interior decoration etc..Different function paints can be chosen for actual purpose in application.
Thickness: 2mm 3mm 4mm 6mm 8mm up to 15mm
Aluminum Skin: AA1100, AA3003 AA3005 AA5052 optional
| Paint: | PVDF, PE ,FEVE, NANO | |
| Skin Alloy: | 1100, 3003, 3005, 5005, 5052 | |
| Skin Thickness | FEVE AND PVDF >0.25MM; PE >0.08MM; | |
| Standard Size | 1220mm x 2440mm, 1250mm x 4000mm, custom-made | |
| Coating Thickness | >25UM (kynar, FEVE) >18um(PE), others negotiable | |
| Coating thickness | ECCA-T1[1995]Comply with customer standard | Kynar 500, 70%+ FC resin 28um + |
| Gloss Deviation | ECCA-T2[1995]30 (60 °) +/- 5 E | Gloss: 10% |
| Colours Deviation | ECCA-T3[1995]ΔΕ≤0.8(CIE - L a b - system) | ΔE: 0.4-0.5 |
| Pencil hardness | ECCA-T4[1995] ≥H | 2H |
| Impact resistance test | ECCA-T5[1995] 1 kg of weight falls from specified heigh | no detainting no cracking |
| T-Bending | ECCA-T7[1996] 0T Without severe cracks | 1T |
| Coating adhesive | not lower than class 1 | not lower than class 0 |
| MEK-test | ECCA-T11[1999] | Over 200 |
| Acid Resistance | 70% HNO3 30mins | ΔE< 5% |
| Boiling test | Bended sheets 1.0T after 5 minutes in boiling water | without cracks |
| Tensile Strenght | 155-180(Mpa) | ≥155 |
| Yield strength | ≥130Mpa) | ≥130 |
| Elongation | ≥3% | ≥3% |
| This test resulte is randomly tested by internal QC department and result in average datebase. | ||
Painting: Kynar 500 PVDF resin with quality dying material.
Color remain bright and vivid after long time duration even under server weathering considtion.
Why Kynar 500 PVDF coating? The one and only resin human could find can survive server neveda desert environment. Choosing ALUCOSUPER aluminum composite panel means the everlasting of your building.
Color: More than 30 standard colors and customerized colors available. Strict ΔE control.
ΔE means the color coherence control in same or different batch, eash the pressue on client's stocking plan or supplying line.
Core: PE flexible core or FR core
Wonderful Wall (Alucosuper) Divisions are subsidiary companies of Changjiang & Jinggong Steel Building (Group) CO,Ltd,(Stock Code: 600496), and the divisions including Anhui Wonderful Wall Color Coating Aluminium Science Technology Co.,Ltd. and Zhejiang Wonderful Wall Building Materials Co,Ltd.. We have been on the market for more than 20 years.
Our Products:
1. All kinds of high quality aluminium composite panels;
2. Color coated aluminium coils / pre painted aluminium coils / sheets; for roofing, gutters, food packages, ACP , Sandwich Panel etc.
3. Embossed aluminium coils / sheets;
4. PPGI / PPGL / GI / Pre painted galvanized steel coils;
5. PCM / VCM for home appliance;
6. Aluminium curtain wall panel;
7. Heat Insulation Wall Cladding Board; (The newest one even worldwide)
Growing up with our valued clients, we'll not spare any effort to meet our clients' demand. We wish to dedicate ourselves to our clients business expansion and will continuously to provide quality and reliable services and build up a long-term business relationship with customers now and in the future.
| Prod Model: | Alucosuper- ACP / ACM |
|---|---|
| Markets: | South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Width: | 700mm - 1590mm |
| Length: | up to 6000mm |
| Alloy: | AA1100,AA3003, |
| Color & Patterns: | Ral, Panton, Wooden, Marble, or as Per Order |
| Surface Finishing: | Coating |
| Panel Thickness: | 4mm |
| Aluminum Thickness: | 0.3mm |
| Function: | Anti- Scratch, Self Cleaning .... |
| Usage: | Sandwich Panel |
| Certification: | ISO |
