Product Specifications
| Prod Model: |
imixpay-rf |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Color: |
White, Black |
| Sdk: |
Yes |
| Certification: |
CE |
Product Description
Professional structure design: with the professional structure design, beyond the traditional ic card reader, perfect combined with mobile drivers.
Safe and Secure: provide safe and secure transactions, provide hardware
based 3DES encryption
Secret key Injection: support to set up a key injection process and software to inject the key through the audio jack into the device
Provide DUKPT KEY Management
support ISO card
Green Initiative: the battery can be charged
Easy to use: simple and best to use, with a smart lanyard.
Provide variety sdk demo:ios,android,windows Phone
3.TECHNICAL SPECIFICATION:
| Model | IMIXPAY-RF |
| Interface | Audio jake , USB |
| Supply Voltage | 3.7V li-battery |
| Supply Current | Idle model 12nA
Operation model 16mA
Charging model 30mA |
| Operating Frequency | 13.56 MHz |
| Smart Card Interface | ISO14443A |
| Sensing Distance | 0~50mm |
| Operating Temperature | 0-50°C |
| Battery capacity | 160mAh |
| Battery life | More than 500 cycles |
| Operation times at the full power | More than 500 standard procedure,?
|
| Working environment | 0-40ºC,Maximum 95% non-condensing, |
| Storage environment | -25-50ºC,Maximum 95% non-condensing, dry storage |
| Dimensions | 48mm(L) X 36mm(W) X 11mm(H) |
| Weight | 30g |
