Price: | Negotiable/Piece |
---|---|
Trade Terms: | FOB,CFR,CIF |
Min Order: | 1/Ton |
Pay Type: | Western Union |
Specifications:
Grade: Gr1, Gr2, Gr5, Gr7, Gr9, GR12, TA0, TA1, TA2, TA3, TA9, TA10, BT1-0, BT1-00 etc.
Standard: ASTM B338, ASTM B337, ASTM B265, ASTM B 861, GB/T3624-95, GB/T3625-2007, GOST22879-86, JIS H4631 etc
Color: Silvery gray
Size: Thickness: 0.7- 50mm
Width:< 2500mm
Length:100-6000mm
Supply condition: Cold rolled, Hot rolled, Extruded
Features: Low-density, light weight, high strength, also have good protection against erosion and corrosion, good processing properties, high and low temperature resistance, anti-acid, anti-alkali. Titanium is resistance to chlorinated water, ozone, iodine, bromine and salt water.
Application:
(1) Plate heat exchanger, plate-type heat exchanger, condenser etc.
(2) Environmental protection equipment, Sea farming, electroplating equipment.
(3) Bicycle frame.
(4) Other industries.
Physical Property:
Standard | Grade | Tensile Strength (MPa) | Yield Strength (MPa) | Elongation (%) |
≥ | ≥ | ≥ | ||
ASTM B265 | GR1 | 240 | 170 | 24 |
GR2 | 345 | 275 | 20 | |
GR5 | 895 | 828 | 10 | |
GR6 | 828 | 483 | 25 | |
GR7 | 345 | 275 | 30 | |
GR9 | 620 | 483 | 25 | |
GR12 | 483 | 345 | 25 |
Chemical Composition:
CHEMICAL COMPOSITION | ASTM Grade | ||||||
(Max. Values) | 1 | 2 | 5 | 7 | 9 | 12 | 23 |
N, Nitrogen | 0,03 | 0,03 | 0,05 | 0,03 | 0,02 | 0,03 | 0,03 |
C, Carbon | 0,1 | 0,1 | 0,1 | 0,1 | 0,05 | 0,08 | 0,08 |
H, Hydrogen | 0,015 | 0,015 | 0,0125 | 0,015 | 0,013 | 0,015 | 0,0125 |
Fe, Iron | 0,2 | 0,3 | 0,4 | 0,3 | 0,25 | 0,3 | 0,25 |
O, Oxygen | 0,18 | 0,25 | 0,20 | 0,25 | 0,12 | 0,25 | 0.13 |
Pd, Palladium | 0,12-0,25 | ||||||
Al, Aluminum | 5,5-6,75 | 2,5-3,5 | 5,5-6.5 | ||||
Mo, Molybdenum | 0,2-0,4 | ||||||
V, Vanadium | 3,5-4,5 | 2,0-3,0 | 3,5-4,5 | ||||
Ni, Nickel | 0,6-0,9 | ||||||
Ti, Titanium | Bal. | Bal. | Bal. | Bal. | Bal. | Bal. | Bal. |
Prod Model: | ASTM B265 GR2 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Thickness: | 0.7- 50mm |
Width: | 2500mm |
Length: | 100-6000mm |
Ti (Min): | 99.6 |
Package: | Export Standard Packing or Customers' Demand |
Place Of Origin: | Shenzhen,China |
Delivery: | 7-30 Days After Deposit |
Type: | Titanium Sheets |
Grade: | GR2 |
Application: | Medical |
Shape: | Square |
Technique: | Cold Rolled, Hot Rolled, Extruded |
