Atlas Copco Portable Screw Air Compressor XATS156Dd
Atlas Copco Air Compressor
Model: XATS156Dd
353CFM, 10.3bar
Atlas Copco screw air compressor
Portable Air Compressor
Diesel Engine
Total capability, total responsibility
Right at the heart of your business, Atlas Copco delivers quality compressed air for superior operational capacity. From compressed air generation to point of use, you can choose from
Our wide range of products to create a complete compressed air system tailored to your specific
Needs. All Atlas Copco products are engineered to integrate seamlessly, ensuring the highest level
Of reliability and energy efficiency. As a result, Atlas Copco can take full responsibility for your
Compressed air infrastructure with a guarantee of best-in-class quality. With a global presence in
Over 150 countries, we can provide an unrivalled service to maintain and continually improve your
Compressed air system performance. Backed by 100 years at the forefront of compressed air, Atlas Copco products offer the finest quality and efficiency. Our goal is to be First in Mind- First in Choice. That is why Atlas Copco's pursuit of innovation never ceases, driven by the dedication to meet and exceed your demands. Always working with you, we are committed to providing the customized air solution that is the driving force behind your business.
Customer benefits
| Compressor Data | XATS156 |
| Free Air Delivery @ Normal Working Pressure | 166 L/S (10 m³ /min ) |
| Normal Working Pressure | 10.3 bar |
| Minimum / Maximum Unloading Pressure | 4 / 11.8 bar |
| Compression Stages | 1 |
| Air Receiver Capacity | 42L |
| Compressor Oil Capacity | 24 L |
| Approximate Air Outlet Temperature | 90° C (Standard) |
| Typical oil content of compressed air | < 5 mg/m³ |
| Fuel Tank Capacity | 175 L |
| Outlet Valve Configuration | 3 x 3/4" G, 1 x 1.5" G |
| Nominal working condition | Inlet pressure 1bar, Humidity0%, Temp20 ° C |
| Sound Pressure Level (ISO2125) | 74 dB(A) +/- 3 |
| Maximum Ambient Temperature at sea level | 50 ° C |
| Maximum Altitude | 3000 m (4500m with assist) |
| Minimum Starting Temperature | -10 ° C / -25 ° C (with assist) |
| Diesel Engine Data | DEUTZ BF4M2012C |
| Horsepower Developed @ Rated Speed | 90 kW |
| Cylinders | 4 in line |
| Cooling System | PARCOOL |
| Engine Coolant Capacity | 14 Liter |
| Engine Oil Capacity | 9 Liter |
| Unloaded Speed / Maximum Loaded Speed | 1700 / 2400RPM |
| Fuel Consumption @ 0% Load / 100% Load | 9.6 / 18.5 kg/h |
| Dimensions | Standard Towing Speed 20 km/h |
| Length | 3941 mm ( within towbar ) |
| Width | 1716 mm |
| Height | 1661 mm |
| Weight ( filled with oil & coolant, Initial fuel ) | 1800 kg |
| Prod Model: | XATS156Dd |
|---|---|
| Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Lubrication Style: | Lubricated |
| Pessure: | 10.3bar |
| Diesel Engine: | Deutz Bf4m2012c |
| Power Source: | Diesel |
| Quality: | High |
| Fuel Tank Capacity: | 175 L |
| Price: | Competitive |
