What Is Automatic Rendering Machine?
Ox Precision Rendering Machine is called plaster machine specialized in rendering cement mortar or gypsum mortar on the walls automatically instead of manual working for saving time and up to 70% of labor cost.
Who Are We?
We are a manufacturer of rendering machine here in China that serves the infrastructure development industry specialized in plastering on brick walls and concrete block walls with abundant practical experiences.
What Is The Feature?
It can plaster the wall automatically and go up and down automatically.
The thickness of the ash can be adjusted.
Easy to operate with one or two people.
The quality is up to the international standard.
High sensitivity leakage protection device is safety and reliability.
How to Operate:
Step 1. Assemble Machine: 120 seconds
Step 2. Move the machine to the wall for rendering: 25 seconds
Step 3. Adjust thevertical and horizontal level: 25 seconds
Step 4. Load any kind of suitable mixture to tank: 30 seconds
Step 5. Render section by section: 65 seconds
How to Operatate Rendering Machines?
1. Assembling Machines
Adjust wire rope straightly as long as cross girdle
Assemble Machines tightly and correctly
2. Move machines close to the wall for rendering.
3. Adjust the thickness of rendering
Put the pipe close the button of wall mostly
Let the wheel touch tube closely, to adjust the render thickness
Twist the wheel to adjust render thickness
Watch the distance between bottom of patter and wall to measure the render thickness
4. Adjust the vertical and horizontal level
To stabilize machines in vertical and horizontal level, please ensure machines go up straightly absolutely.
5. Step on Hydraulic Pedal
Step on hydraulic pedal until you can't step it down any more.
Make sure those pipes and 2 upright tubes are 100% tightly touch to the ceilings by stepping on the hydraulic pedal, people can't move upright tubes around.
If it's not tight, please exchange oil cylinder.
6. Load the mixture to tank
You have to load 20kg mixture at least to render one side of wall if your model is 0X800B, constantly add more mixture when machines operation.
7. Turn on the button
A. Green button: Start switch
B. Red (Black) button: Stop switch (only a few seconds) usually for adding more mixture
C. Big Red Knob: Emergency stop (stop forever)
8. Render the first section
The machine will stop on the top for 2~5 seconds, its set up in the factory.
9. Smooth the first section
10. Move the machines for next render
11. Then do steps above again.
Customer Service Center
If there is anything wrong with the machine.
1. The free repairing period of the conveyer belt, the trowel and the motor is guaranteed for one year.
2. The free repairing period of the electric appliance and the vibrators is three months.
3. The nylon wheel, the hoisting cable and the chain are not included in the free repair guarantee.
4. The free repairing period starts on the date when the machine is bought.
Safety and Protection
1. If the trowel is not at the plastering angle, even if you press the starting switch, the machine doesn't start in order to avoid the damage of the trowel.
2. When starting, if the motor turns in the opposite direction, the power will be cut off automatically so as to keep the hoisting cable in good order. Turn the reversing switch for phase commutation, then the motor starts.
3. If the machine is held up while going down, the power will be cut off automatically to keep the hoisting cable in good order.
4. Replace a new one in time when the surface of the hoisting cable is not smooth. In case the cable is broken, the machine will stop when it goes down 20cm at an abnormal speed.
We are a Chinese manufacturer of automatic rendering machine, it can save labor cost and time up to 70% on working on all kinds of walls with all kinds of mixture.
Our clients and their partners in the construction industry, both here in China and much of the developing world, are being awarded large contracts in areas where the local labour market has a shortage of skilled craftsmen and a high percentage of unskilled manual labour. Since deadlines, reputation and future business prospects are at stake, getting the job done quickly and effectively whilst ensuring that standards are upheld, present an interesting design problem. Given these market realities, our solution was to design rendering machines that required as little training as possible, while making sure that operators could confidently and consistently achieve superior results.
