FREE sea shipping, FREE spare parts, FREE tools.
Features
1. Once coating: Escape from boring and repeating manual rendering
2. Professional finishing: Smooth and flat mirror finishing in horizontal and vertical level
3. Easy to render the area above and below window, bathroom, corridor, store and warehouse etc
4. Reach the top of wall completely, without 1mm empty space remaining
5. Easy to move with 360 degree angle wheel
6. Fast speed: Up to 70m2/hour
7. Flexible render thickness
8. Easy operating
Cautions
1. Since the machine works in wet surroundings all the time, the leakage protector must be installed (or otherwise we are not responsible for any electric shock accident).
2. While the machine is working, do not stand under the machine. Moreover, keep any part of your body away from the machine (we shall not burden any responsibility if any accident like that occurs).
3. After the settlement of the machine:
1. ) Only when you lift the reversing lever to turn the trowel to the plastering angle, will the machine start. Start by pressing the starting switch. This is a self protective function to avoid damaging the trowel.
2. ) The conveyer belt will not work unless the trowel is close to the conveyer belt.
3. ) If the machine doesn't stop or go down automatically, you have to turn the reversing switch manually. 4. ) Just keep the reversing switch on. No phase commutation is needed. For example, turn it to the position "forward" to raise the machine. When the machine reaches the ceiling and stops automatically, turn it to the position "stop". And then turn it back to the position "forward", the machine will descend. You MUSTN'T turn it to the position "backward" to avoid the damage of the machine.
4. Regularly examine all the screws in case the screws are loose.
Easy Replacement
1. Loosen the fastening screw in the front axle of the conveyer belt; In this way it is easy to remove the conveyer belt by hand.
2. Easy and convenient to replace the hoisting cable and to erect the vertical supporting poles in rooms of
Different heights. All you need to do is to lift the two pieces of cable with both hands.
3. The machine is made under the universal uniform standard. It is easy to replace all the parts.
It is important to thoroughly wash and maintain without delay in order to
Keep your machine in good condition.
A. Washing
1. Wash the inside and the outside of the conveyer belt, the vibrators, the front and the rear side of the trowel, the hod, the hydraulic sleeves, the lifting wheels, the truckles and the surface.
2. Wash the corners between the main transmission shaft and the conveyer belt on both sides of the machine.
3. Washing the truckles. Pry the machine upwards with the square tube matching with the machine and then wash the turning parts of the truckles using a mineral water bottle with a hole in its cover until
They can turn easily and freely.
4. Wash the vertical supporting poles with a soaked cloth or a soaked woven bag.
5. Remove the vertical supporting poles and protrude the two
Hydraulic sleeves with the hydraulic device and then wash the
Nylon wheels with high-pressure water.
B. Maintenance
Oil the guide post in the oil window, the turning parts of the reversing lever of the trowel, the clutch disc of the electromagnetic clutch, the inside of the hydraulic sleeves, the chain, the hoisting cable and all the fasteners or coat them with oil once every day.
Model Comparation
|
MODEL |
0X800A |
0X800B(HOT) |
OX1000 |
OX1350 |
Convey Belt |
YES |
NO |
NO |
YES |
Size(machine) |
64cmX80cmX65cm |
80cmX65cmX50cm |
100cmX60cmX50cm |
1350cmX911cmX50cm |
Pack Size(big) |
106cmX78cmX71cm |
100cmX80cmX84cm |
120cmX80cmX84cm |
142cmX97.5cmX65cm |
Pack Size(Small) |
257cmX24cmX27cm |
240cmX21cmX21cm |
240cmX21cmX21cm |
256cmX24cmX25cm |
Volume |
0.754m³ |
0.782m³ |
0.915m³ |
1.053m³ |
Weight(N) |
160kg |
215kg |
360kg |
270kg |
Weight(G) |
180kg |
235kg |
380kg |
250kg |
Speed |
70square meters/hour |
Thickness |
0.5cmX3cm |
Voltage |
220V/380V (Appointed voltage is allowed) |
Hight |
up to 3.5m |
up to 3.5m |
up to 3.5m |
up to 5m |
Operation |
Middle |
Easy |
Easy |
Middle |
Transportation |
Air |
Sea |
Sea |
Sea |
Color |
Yellow/Blue |
Yellow/Blue/Silver |
Yellow/Blue/Silver |
Yellow/Blue |
We are a Chinese manufacturer of automatic rendering machine, it can save labor cost and time up to 70% on working on all kinds of walls with all kinds of mixture.
Our clients and their partners in the construction industry, both here in China and much of the developing world, are being awarded large contracts in areas where the local labour market has a shortage of skilled craftsmen and a high percentage of unskilled manual labour. Since deadlines, reputation and future business prospects are at stake, getting the job done quickly and effectively whilst ensuring that standards are upheld, present an interesting design problem. Given these market realities, our solution was to design rendering machines that required as little training as possible, while making sure that operators could confidently and consistently achieve superior results.
