Quality Assurance: UL: E352422; ISO14001: 128630; ISO9001: 128629
1. Board thickness: 0.2mm-6.0mm
2. Laminate: FR-4, Taconic, Rogers, TG170, TG180, CEM-1.
3. Layers: SS, DS, ML, Single side, Double side, Multilayer, 1-24Layer
4. Outer / inner Coppers: 1/1 oz, 1/2 oz, 2/2 oz, 2 oz, 3 oz, 4 oz.
5. Multilayer stack up: Stack up, controlled impedence.
6. Pcb size: Unit size, panel size, tooling strips, tooling holes and fudicials.
7. Min hole size: 0.2mm
(Shape tolerance± 0.13mm, hole tolerance: PTH± 0.075mm; NPTH: ± 0.05mm)
8. Min line width: 0.1mm
9. Min line spacing: 0.1mm
10. Solder mask color: Green, Blue, Red, Black, Yellow, White
11. Legend color: White, Yellow, Black, Blue, Red
12. Surface finshed: HAL(Tin / Lead), HAL(Lead Free), Immersion gold, Immersion Silver,
Immersion Tin, Gold Plated(Soft Gold), OSP(ENTEK).
13. Certificate: UL, ISO9001, ISO14001, SGS, RoHS, QS9000.
14. Profiling: CNC, Routing, Punching, Beveling, V-cut, V-score, Counter sink.
15. Test: E-test, Fixture, Fly-test.
16. Special technique: Buried and bling vias, controlled impedance, BGA.
17. Package: Vacuum package, Seal package.
18. Shipping: FOB HongKong, CIF, Air Transportation, DHL, UPS, Fedex.
Wlcome inquery
Contact Person: Christin
Mobile: 86-15361573222
Shenzhen Posin Circuit Technology Co., Ltd. was established in April, 2008, After
years'efforts, the company has expanded rapidly and keptIntroducing
new production equipments. We have also trained a professional team
and perfected the quality management system ranging. the
manufacture ability of our company is expanded rapidly. The annual
output of double-sided and multi-layer PCB exceeds 100, 000
square meters.
