AWS F6AZ SJ301 WELDING FLUX
1. Donescription
AWS-A5.17 is a kind of burning welding flux specially used for X60-X70 grade pipe submerged welding and its basicity is about 1.8. It is white round particle and the granularity is 2.0-0.4MM. It can be used with DC-AC and when DC, welding wire connects with positive pole. The electric arc is steady, easy to deslagging and welding line is formed well and beautiful. The welding line has good toughness of low temperature impacting.
Because it uses special production technology, the welding flux has good performance of resisting to moist and it can save consumption in the process of welding.
2. Application
1. Weld many kinds of steel used in pipeline coordinate(such as X52, X60, X65, X70 and so on) with proper
Welding wire(H08C, H08MnA, H08MnMoA, H08Mn2MoA)
2. Muti-layer welding, double side single channel welding, multi-wire welding and narrow gap submerged arc welding.
3. Welding Flux Reference Composition(%)
SiO2+TiO2CaO+MnOAl2O3+MnOCaF2SP
18-2528-3523-3016-25≤ 0.06≤ 0.08
4. Melting Metal Mechanical Performance
Wire matchedYield Stress
MPaTensile Strength
MPaElongation
%AKV(J)
EH14(H10Mn2)≥ 375490-660≥ 22≥ 34(-20° C)≥ 27(-40° C)
Factory scale
Certificate
Packing:
1 25kg-300kg/coil
2 200kg 250kg iron or wooden plate
3 25kg iron basket
4 as requested
Delivery:
MOQ: 5MT, Net weight delivery
Time: 10~20 days, Qingdao Port
Package: OEM package, Neutral carton, SOLID brand carton
1. Delivery time to North of America is 30~35 days.
2. Delivery time to Asia countries&middle east is 5~30 days.
3. Delivery time to Africa countries is 40~50 days.
4. Delivery time to Euro countries is 30~40 days.
SiO 2 +TiO 2 | CaO+MnO | Al 2 O 3 +MnO | CaF 2 | S | P |
18-25 | 28-35 | 23-30 | 16-25 | ≤0.06 | ≤0.08 |
4.Melting Metal Mechanical Performance
Wire matched | Yield Stress MPa | Tensile Strength MPa | Elongation % | AKV(J) |
EH14(H10Mn2) | ≥375 | 490-660 | ≥22 | ≥34(-20°c) | ≥27(-40°c) |
