Product Description:
1.The New Delivery ServiceWe apply the fully computerized modular elevator special control system,effective and reliable drive mode,sensitive and flexible VVVF variable frequency door machine for Lingzhi serial freight elevator so that our elevator can haverelaxed transport under various work conditions.High strength car structure,anti-collision strip,photocell door setting can satisfy all kinds of the freight transport.They are also applicable for different building structures.As a result,we can tackle more and more transport tasks at ease and creat a completely new freight carry concept as well.
2.Highly accurate levelingLeveling accuracy can be controlled within millimeter-sized range.
3. Ac variable frequency door machineIt applies variable frequency door machine control system,AC variable frequency motor,variable frequency door machine mechanical system with the advanced technology .It not only increases the elevators' safely and sensitivity in the running,but also saves energy and consumption loss.It suits modern transport requirements which are progressively increasingly day by day.
4, Excellent torque propertiesMaximum feature of Lingzhi elevator VVVF speed regulation lies in its constant torque features.No matter how light or heavy the load is,it never affects the running speed;confortable travel and the leveling accuracy.
Freight Elevator Construction Specifications:
| Speed | Load | Car size | Hoistway | Machine room | Door | Door |
| (m/s) | (kg) | (mm) | size(mm) | size(mm) | width | height |
| 0.5/1.0 | 630 | 1100*1400 | 2100*1800 | 2500*3400 | 1100 | 2100 |
| 0.5/1.0 | 630 | 1100*1400 | 2100*1872 | 2500*3400 | 1100 | 2100 |
| 0.5/1.0 | 1000 | 1300*1850 | 2350*2300 | 2800*3500 | 1300 | 2100 |
| 0.5/1.0 | 1000 | 1300*1850 | 2350*2322 | 2800*3500 | 1300 | 2100 |
| 0.5 | 1000 | 1450*1656 | 2250*2160 | 2700*3500 | 1200 | 2100 |
| 0.5 | 1000 | 1450*1562 | 2250*2160 | 3000*3500 | 1200 | 2100 |
| 0.5 | 2000 | 1500*2800 | 2700*3280 | 3500*4000 | 1500 | 2100 |
| 0.5 | 2000 | 1500*2800 | 2700*3272 | 3500*4000 | 1500 | 2100 |
| 0.5 | 2000 | 1950*2156 | 2850*2660 | 3500*4000 | 1500 | 2100 |
| 0.5 | 2000 | 1950*2062 | 2850*2660 | 3500*4000 | 1500 | 2100 |
| 0.5 | 3000 | 2000*2900 | 2950*3380 | 3500*4500 | 1500 | 2100 |
| 0.5 | 3000 | 2000*2900 | 2950*3372 | 3500*4500 | 1500 | 2200 |
| 0.5 | 3000 | 2400*2400 | 3600*2880 | 4000*4500 | 2000 | 2400 |
| 0.5 | 3000 | 2400*2400 | 3600*2872 | 4000*4500 | 2000 | 2400 |
| 0.25/0.5 | 5000 | 3000*3000 | 4400*3600 | 4800*4500 | 2600 | 2400 |
| 0.25/0.5 | 5000 | 3000*3000 | 4400*3600 | 4800*4500 | 2600 | 2400 |
| Standard Function List |
| Automatic running |
| Attendant running |
| Automatic adjustment of door open holding time |
| Door re-open at current floor |
| Car call cancel |
| Parking |
| Light curtain protection |
| Overload stop |
| Inspection operation |
| Troubleshooting |
| Auto-landing with fault |
| Door close repeat |
| Top/bottom limit and final limit protection |
| Down running protection |
| Up running protection |
| Safety circuit protection |
| Door interlock protection |
| Main contactor protection |
| Brake detecting protection |
| Micro push button |
| Running state display |
| No stop floor set |
| Hoistway self-learning |
| Emergency lighting |
| Emergency car lighting |
| Emergency electric operation |
| Five way intercom |
| Alam bell |
| Fan& light automatic off |
| Optional Function List |
| Door close delay |
| Fire emergency return |
| Double door control |
| Arrival gong |
| Sub-C.O.P. |
| IC card control |
| Automatic Rescue Device |
| Traction machine monitor |
