Product Specifications
| Prod Model: |
ACM810 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| CPU: |
32bit |
| Resolution: |
500dpi |
| User Capacity: |
1000 |
| Records: |
100.000 |
| Communication: |
TCP/IP .USB .SD Card |
| Identify: |
Fingerprint .RFID .Passwork |
Product Description
Biometric & Fingerprint Support Em/Mifare Card Time Attendance and Software with TCP/IP Communication
Features:
1): Strictly follow the national security product standard. Suitable for the entrances and exits of office, factory, hotel, school, et
2): Adopting the Energy-saving fingerprint sensor and power management function, makes the product perfect.
3): Easy to learn, once enroll the fingerprint, you can share it on other Realand terminals.
4): 2.4 inch TFT screen.
5): USB Flash Drive Download + USB Communication + TCP/IP
6): Fingerprint + Password + ID Card.
Specs:
ModelACM810
TFT2.8 inch TFT (320*240)
Fingerprint Sensor(Energy-saving)Optical Fingerprint Sensor (Resolution: 500DPI)
CPU32bit CPU
Fingerprint Capacity1, 000
Log Capacity100, 000 events
CommunicationUSB ( TCP/IP Optional )
Identification ModeFingerprint, Password, Proximity Card
Proximity Card125Khz, EM4100 or other Compatible Contactless ID Card
USB Flash Drive Up/DownloadAvailable
Record QueryAvailable(people can query their own attendance record after authentication)
Rotational AngleTotal Rotational Angle
Identification Time≤ 1s
FRR≤ 0.1%
FAR≤ 0.0001%
Operating ModeOff-line / Online
Authentication Mode1: 1, 1: N
LanguageChinese, English, Korean
Voice PromptAvailable
BellBuilt-in Timing Bell
Self TestAvailable
Power ManagementAuto Sleep Time, Auto Power Off Time
Power AdapterDC 12V/1A
Operating EnvironmentOperating Temp: -10 ~ +60 degree, Humidity(RH): 20%~80%
Size of the Terminal180(L) × 134(W) × 36(H) mm
|
Model |
ACM808 |
|
TFT |
2.4 inch TFT (320*240) |
|
Fingerprint Sensor |
(Energy-saving)Optical Fingerprint Sensor (Resolution: 500DPI) |
|
CPU |
32bit CPU |
|
Fingerprint Capacity |
1, 000 |
|
Log Capacity |
100, 000 events |
|
Communication |
USB, TCP/IP |
|
DHCP |
Available |
|
Identification |
Fingerprint, Password, Proximity Card |
|
Proximity Card |
125Khz, EM4100 or other Compatible Contactless ID Card |
|
USB Flash DriveUp/Download |
Available |
|
Record Query |
Available(people can query their own attendance record after authentication) |
|
Rotational Angle |
Total Rotational Angle |
|
Identification Time |
≤ 1s |
|
FRR |
≤ 0.1% |
|
FAR |
≤ 0.0001% |
|
Operating Mode |
Off-line/Online |
|
Authentication Mode |
1: 1, 1: N |
|
Language |
Chinese, English, Korean |
|
Voice Prompt |
Available |
|
Bell |
Built-in Timing Bell |
|
Self Test |
Available |
|
Power Management |
Auto Sleep Time, Auto Power Off Time |
|
Power Adapter |
DC 12V/1A |
|
Operating Environment |
Operating Temp: -10 ~ +60, Humidity(RH): 20%~80% |
|
Size of the Terminal |
180(L) × 134(W) × 36(H) mm |
