Product Specifications
| Prod Model: |
SM203 |
| Markets: |
North America,Oceania,Mid East,Eastern Asia,Western Europe |
Product Description
Programmable OTP sound module for greeting card, easily apply the module to your cards
OTP sound module for seans greeting card, programmable the sound and burn to the chipset, including voice message, songs, melody.
How to work with the OTP sound module?
Sound module with dobule adhesive on bottom side, peel off the paper outside, and stick the module to the greeting cards. For some special festival or pomotional event. Such as Birthday, fasther's day, Thanks giving day, christmas day, You are the champion.
There is one slide tongue to cut off the circuit, once the slid tongue move out and the metal pins connected, the device would be activated to start playback the pre-record message or songs. Once the slide tongue move back, the circuit cut off and stop playing.
Specification:
1. Module size; 11*4cm,
2. Customized sound file or message, starandard sound source also available;
3. Operated by button cell AG10 * 3 pcs; Working voltage: 3~4.5V
4. Speaker size: Diameter 27mm, with plastic housing;
5. Module bottom side with adhesive tape, easily to stick the module on cards;
6. Insulation sheet added prevent the device working accidently
7. Sound file duration time: Up to 60 seconds;
8. All of the material conpliant with RoHS, CE, and EN71 standard
Recon, a division of Wingroup, was established in the year of 2004, specialize in sound module, LED flashing product and PC peripheral research & development, production and distribution to the world. Setting up sound module and LED flashing product division in Dongguan, and PC peripheral product division in Shenzhen. Recon provides OEM & ODM service for omestic and abroad customers. Continuous develop new products with competitive price and marketing demands, thanks to our strong and senior R&D team. Sufficient production equipment and comprehensive quality control process, assure high efficiency and perfect service for worldwide customers.
Full of self-innovation inspiration and brain-storm crew, the product ID, mechanical and electronic designed in-house. Senior engineers around 10persons, we strictly keep confidential for customers related to product designs, sketch and prototype. Fast action, multi-solution, positive and religious attitude to design product; Honor customer, cost efficiency and reliable quality is cooperation base; Aim to OEM & ODM target timeline and budget, pursue better and better, strive for excellent executive style and self-innovation team.
Since from the company beginning, we insist high standard and strict stipulation to self-managed internally, continue to make progress. Recon awards ISO 9000 certificate in 2012. The factory production strictly manages as 5S standard and ERP system. The plant occupy 8000 square meters, 200 operators, 3 sets injection machine, 5 sets SMT machine, and 5 production line. Mould and painting workshop in-house. Enable provide various kinds of product service for customers request, besides helpful to control the quality and enhance production efficiency. Under global marketing strategy, all of the products are compliant with CE and RoHS II standard. Recon builds own company culture as business ongoing: Responsibility, cooperation and share
Basis of honesty business principle, "Product innovation, reliable quality and cost efficiency" is our vision, looking forwarding to building long term stable and win-win business cooperation with the worldwide customers.
Recon, design for you always
