Product Specifications
| Prod Model: |
WS-X6148-FE-SFP |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Type: |
Wired |
| Firewall: |
Firewall |
| Application: |
Enterprise |
| Transfer Rate: |
10/100/1000Mbps |
Product Description
Cisco WS-X6148-FE-SFP General Information Manufacturer: Cisco Systems, Inc
Brand Name: Cisco
Product Name: Catalyst 6500 48-port 100BASE-X Classic Interface Module
Product Type: Expansion Module Cisco WS-X6148-FE-SFP Interfaces/Ports
Interfaces/Ports: Not ApplicableInterfaces/Ports
Details: Not Applicable Cisco WS-X6148-FE-SFP Media & Performance
Data Transfer Rate: 100Mbps Fast Ethernet Cisco WS-X6148-FE-SFP I/O Expansions Expansion Slots: 48 x SFP Cisco WS-X6148-FE-SFP Management & Protocols Management:
CiscoWorks network management platform
Simple Network Management Protocol (SNMP) Versions 1, 2, and 3
Four Remote Monitoring (RMON) groups (statistics, history, alarms, and events)
CiscoWorks network management platform
Simple Network Management Protocol (SNMP) Versions 1, 2, and 3
Four Remote Monitoring (RMON) groups (statistics, history, alarms, and events)
Protocols: SNMPProtocols: VRRPProtocols: GLBPProtocols: PVST+Protocols: RSTPProtocols: MSTPProtocols: HSRPProtocols: PVRST Cisco WS-X6148-FE-SFP Memory Memory: 5.4KB Buffer Memory per PortMemory: 256MB Buffer Memory Cisco WS-X6148-FE-SFP Controls/Indicators Status Indicators:
Status
Link good
Status
Link good
|
Manufacturer |
Cisco |
|
Manufacturer Part # |
WS-X6148-FE-SFP |
|
Cost Central Item # |
10111197 |
|
Product Description |
Cisco Classic Interface Module - Switch - 48 x SFP - plug-in module - for Catalyst 6503, 6503-E, 6506, 6506-E, 6509, 6509-E, 6509-NEB, 6509-NEB-A, 6513 |
|
Device Type |
Switch |
|
Enclosure Type |
Plug-in module |
|
Ports |
48 x SFP |
|
Routing Protocol |
HSRP, VRRP |
|
Remote Management Protocol |
SNMP 1, SNMP 2, RMON 1, RMON 2, RMON 3, RMON 9, SNMP 3 |
|
Features |
Full duplex capability, Cisco Fast EtherChannel, VLAN support, manageable, Weighted Round Robin (WRR) queuing |
|
Compliant Standards |
IEEE 802.3, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1s, IEEE 802.3ah |
|
Approximate Dimensions (WxDxH) |
14 in x 16 in x 1.2 in |
|
Designed For |
Catalyst 6503, 6503-E, 6506, 6506 chassis, 6506-E, 6509, 6509 chassis, 6509-E, 6509-NEB, 6509-NEB-A, 6513, 6513 chassis |
