Product Specifications
Prod Model: |
ox1350 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Size: |
1350mmx91mmx50mm |
Color: |
Blue Yellow Red Silver |
Rendering Height: |
5 Meters |
Rendering Thickness: |
2~30mm |
Voltage: |
220V/380V/Customized |
Weight: |
270kg |
Percentage: |
70% |
Shipping: |
Sea Free |
Rendering Speed: |
70square Meters |
Type: |
Electrostatic Spraying Equipment |
Certification: |
REACH |
Method Type: |
Automatic |
Application: |
Porcelain Spraying Equipment |
Product Description
This is Ashley from Ox Precision Rendering Machines.
We are a manufacturer of rendering machines here in China that serves the infrastructure development industry specialized in plastering onto brick walls and concrete block walls with abundant practical experiences.
What Is Automatic Rendering Machine?
Ox Precision Rendering Machine is called plaster machine specialized in rendering cement mortar or gypsum mortar on the walls automatically instead of manual working for saving time and up to 70% of labor cost.
What Is The Feature?
It can plaster the wall automatically and go up and down automatically
The thickness of the ash can be adjusted
Easy to operate with one or two people
The quality is up to the international standard
High sensitivity leakage protection device is safety and reliability
How to Operate:
Step 1. Assemble Machine: 120 seconds
Step 2. Move the machine to the wall for rendering: 25 seconds
Step 3. Adjust thevertical and horizontal level: 25 seconds
Step 4. Load any kind of suitable mixture to tank: 30 seconds
Step 5. Render section by section: 65 seconds
We have totally 4 models, and please take a look at SHEET below
Payment method avilable in our company:
Negotiable
Delivery method:
Sea(free) shipping provided by our side.
Other shipping methods are paid by your side
Delivery time:
10 t~35 days by sea
Loading Port:
Shen Zhen
Customer Service Center
If there is anything wrong with the machine.
1. The free repairing period of the conveyer belt, the trowel and the motor is guaranteed for one year.
2. The free repairing period of the electric appliance and the vibrators is three months.
3. The nylon wheel, the hoisting cable and the chain are not included in the free repair guarantee.
4. The free repairing period starts on the date when the machine is bought.
Safety and Protection
1. If the trowel is not at the plastering angle, even if you press the starting switch, the machine doesn't start in order to avoid the damage of the trowel.
2. When starting, if the motor turns in the opposite direction, the power will be cut off automatically so as to keep the hoisting cable in good order. Turn the reversing switch for phase commutation, then the motor starts.
3. If the machine is held up while going down, the power will be cut off automatically to keep the hoisting cable in good order.
4. Replace a new one in time when the surface of the hoisting cable is not smooth. In case the cable is broken, the machine will stop when it goes down 20cm at an abnormal speed.
Questions:
1, May I know the model you choose? The weight is quite different.
2. May I know the name of sea port nearest your city?
3. What is the voltage and Herz in your country?
Thank you very much
Ashley
Tel: 0086-139-8211-4575
Ox Precision Rendering Machines
Model Comparation
|
MODEL |
0X800A |
0X800B(HOT) |
OX1000 |
OX1350 |
Convey Belt |
YES |
NO |
NO |
YES |
Size(machine) |
64cmX80cmX65cm |
80cmX65cmX50cm |
100cmX60cmX50cm |
1350cmX911cmX50cm |
Pack Size(big) |
106cmX78cmX71cm |
100cmX80cmX84cm |
120cmX80cmX84cm |
142cmX97.5cmX65cm |
Pack Size(Small) |
257cmX24cmX27cm |
240cmX21cmX21cm |
240cmX21cmX21cm |
256cmX24cmX25cm |
Volume |
0.754m³ |
0.782m³ |
0.915m³ |
1.053m³ |
Weight(N) |
160kg |
150kg |
360kg |
270kg |
Weight(G) |
180kg |
180kg |
380kg |
250kg |
Speed |
70square meter /hour |
Thickness |
0.5cmX3cm |
Voltage |
220V/380V (Appointed voltage is allowed) |
Hight |
up to 3.5m |
up to 3.5m |
up to 3.5m |
up to 5m |
Operation |
Middle |
Easy |
Easy |
Middle |
Transportation |
Air |
Sea |
Sea |
Sea |
Color |
Yellow/Blue |
Yellow/Blue/Silver |
Yellow/Blue/Silver |
Yellow/Blue |
We are a Chinese manufacturer of automatic rendering machine, it can save labor cost and time up to 70% on working on all kinds of walls with all kinds of mixture.
Our clients and their partners in the construction industry, both here in China and much of the developing world, are being awarded large contracts in areas where the local labour market has a shortage of skilled craftsmen and a high percentage of unskilled manual labour. Since deadlines, reputation and future business prospects are at stake, getting the job done quickly and effectively whilst ensuring that standards are upheld, present an interesting design problem. Given these market realities, our solution was to design rendering machines that required as little training as possible, while making sure that operators could confidently and consistently achieve superior results.
