Product Specifications
| Prod Model: |
JF-ETP-310B |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| USB Ports: |
4PC |
| Color: |
White and Black |
| CPU Type: |
PC Share/Terminal |
| Supporting Memory Capacity: |
2GB |
Product Description
1. Build in WinCE 6.0;
2. Support XP/2003/Vista/7/2008 (32bit & 64bit);
3. Ports: 1 RJ-45 LAN port; 4 USB 2.0 ports; 1 DC in port; 2 Audio jacks: Speaker-out andmic-in; (Microphone for single user mode);
4. Support unlimited users;
5. Display support Max 1280*1024@85Hz, 16bit/64K colors; Widescreen 1440*900 support and support touch screens;
6. CPU: 800M; Memory: 128M(Max 256M); Storage flash: 128M(Max2G);
7. Can support WiFi (Option);
8. Limitless distance for connecting network.
Dual-working style
1. Sharing work mode
With VDP technology, you can set up sharing cloud computing network, the desk of Cloud Computing Terminal use the resources of the main HOST, and run remote desktop. It works just like a full typical desktop computer.
2. Mini PC mode
Cloud Computing Terminal can work as a stand-alone minicomputer. You can surf internet, enjoy cloud computing, run simplify Office software and even download data to your USB flash memory or other moving HDD.
10-second Quick Start function and nice print function supported.
Compared to the long time starting process of traditional desktop computer, Cloud Computing Terminal may bring you super surprise; It takes only 10 seconds to start. Cloud Computing Terminal support printing function under both working modes, overcomes the traditional limitations of network computer. Cloud Computing Terminal support WiFi.
Note: The number of users on individual host will depend upon the host system capabilities as well as the applications used and performance expectations for those applications. It is recommended that new customers test their application(s) before adding additional users. Does not support 3D games or full screen home theater video applications. Application software and OS licenses for the host PC may be required by the respective software vendor and must be purchased separately.
|
Hardware |
|
Size |
Access Device: 115*115 *26 mm Shipping Size: 138*138*98mm |
|
Weight |
310B Access Terminal: 180g
Shipping Weight (includes power adapter, packaging, documentation, etc. ): 400g |
|
Power Supply |
Input: 100-250 VAC, 50-60 Hz; Output: 5 VDC, 2 A
Nominal consumption: 5 Watts |
|
Front LED Indicators |
Power: connection to power supply LAN: connection to network
Ready: connection to host PC |
|
Rear Ports |
|
01 – Microphone in
02 – Speaker Out DC Power Input
03 – 4 USB 2.0 Ports,
04 – LAN port (RJ45)
05 – Video port
06 –DC Power Input
07 - On/Off Power Switch (top) |
|
Connection to Host PC |
Onboard LAN 10/100 Mb/s connection |
|
Video Resolution |
Max 1280*1024, 16bit/64K colors; Widescreen 1440*900 support, or 24Bit |
|
Audio |
Stereo output via microphone and speaker port |
|
CPU |
Onboard 800 MHz |
|
Memory |
Onboard 128MB RAM (or 256MB) |
|
Storage |
Onboard 128MB Flash (or 2GB) |
|
Firmware feature |
Windows CE 6.0 integrated RDP protocols, Support system upgrading. |
|
USB |
4 USB Ports,USB Wi-Fi, USB touch screen,
Through USB converters connected PS / 2 mouse and keyboard |
|
TERMINAL SERVICES SOFTWARE |
Max # Users
Per PC |
100 users* when using a server host OS (i.e. Windows Server 2003/2008)
30 users when using a desktop OS (i.e. Windows XP/7) |
|
User Software |
310B terminal services software |
Supported Operating
Systems |
Windows XP, Windows Server 2000/2003, Windows Vista, Windows 7, Windows Server2008,, Linux and all other OS which has terminal working permission. |
|
SYSTEM REQUIREMENTS AND OPTIONS |
|
Kit Contents |
310B Kit includes access terminal, power supply, software installation & user's guide and other peripherals are NOT included and must be purchased separately. |
