About US
1. Yueqing Kangling Electric Appliance Factory specializing in the R&D, manufacture and sale of low voltage electric applicants, such as MCB, MCCB, AC contactors, and other related products for 8 years.
2. Our factory, with the aim of high quality and low price, offers superior OEM services, and has accumulated abundant experience in manufacturing low voltage
Electric appliances.
3. We have export experience to Asia, Africa. Expecially in Middle East.
LC1-D 09 10 electrical contactor FUCTIONS! ! !
CJX2-D SERIES AC CONTACTO IS SUITABLE FOR USING IN THE IRCUITS UP TO THE RATED VOLTAGE 660V AC 50 Hz OR 60 Hz, RATED CURRENT UP TO 620A, FOR MAKING, BREAKING, FREQUENTLY STARTING &CONTROLLING THE AC MOTOR. COMBINED WITH THE AUXILIARY CONTACTOR BOCK, TIMER DELAY & MACHINE-INTERLOCKING DEVICE etc, IT BECOMES THE DELAY CONTACTOR, MECHANIACL INTERLOCKING CONTACTOR, STAR-DELTA STARTER. WITH THE THERMAL RELY, IT IS COMBINED INTO THE ELECTROMAGNETIC STARTR. THE PRODUCTS COMPLY WITH IEC60947-4.
Packing details
MODEL: LC1-D0910 40*26*20mm/ 50PCS /ctns N. W. 16KG
LC1-d 1210 40*26*20/ 50PCS /ctns N. W. 16KG
LC1-d 1810 40*26*20/ 50PCS /ctns N. W. 16KG
LC1-d 2510 44*31*22 50PCS /CTN. N. W. 25 kg
LC1-d 3210 44*31*22 50PCS/CTN N. W. 26kg
LC1-d 4010 41*27*26 20PCS/ctns N. W. 23kg
LC1-d 5010 41*27*26 20 PCS/ctns N. W. 23kg
LC1-d 6511 41*27*26 20 PCS/ctns N. W. 23kg
LC1-D8011 47*27*29 20PCS/CTN N. W. 32kg
LC1-D9511 47*27*29 20PCS/CTN N. W. 32 kg
LC1-D AC contactor
1. Model: LC1-D09 AC contactor, LC1-D12 AC contactor, LC1-D18 AC contactor, LC1-D25 AC contactor, LC1-D32 AC contactor, LC1-D40 AC contactor, LC1-D50 AC contactor, LC1-D65 AC contactor, LC1-D80 AC contactor, LC1-D95 AC contactor
2. LC1-D AC Contactor Applications:
1). It is suitable for frequency 50/60Hz, rated voltage up to 660V, rated operation current 9~95A under AC-3 duty.
2) It is mainly used for making / breaking electric circuits at a long distance & for frequent starting / stopping & controlling AC Motors.
3) It can become the time-delay contactor, mechanical interlocking contactor, star-delta starter with other parts...
3) With the thermal relay, it is combined into the electromagnetic starter LC1-D AC Contactor
5) The products COM-ply with IEC60947-4-1 standard.
3. LC1-D AC contactor: Main technical Parameter
Rated insulated voltage: 660V
Type: LC1-D09, LC1-D12, LC1-D18, LC1-D25, LC1-D32, LC1-D40, LC1-D50, LC1-D65, LC1-D80, LC1-D95
UnderAC-3, 380V---
--- rated operation current (A) 9, 12, 18, 25, 32, 40, 50, 65, 80, 95
Conventional thermal current (A): 20, 20, 32, 40, 50, 60, 80, 80, 110, 110
. 660V: 5.5kW, 7.5kW, 10kW, 15kW, 18.5kW, 30kW, 33kW, 37kW, 45kW, 55kW
Max making current: 10 times of rated current (AC-3, 380V)
Max breaking current: 8times of rated current (AC-3, 380V) LC1-D AC Contactor
AC-3 electric life: CJX2-09~32(LC1-D09, LC1-D12, LC1-D25, LC1-D32) 1 000 000 times;
CJX2-40\50\65 (LC1-D40, LC1-D50, LC1-D65) 800 000 times;
CJX2-80\95 (LC1-D80, LC1-D95) 600 000times
Mechanical life: CJX2-09~32(LC1-D09, LC1-D12, LC1-D25, LC1-D32) 10 million times
CJX2-40\50\65 (LC1-D40, LC1-D50, LC1-D65) 8 million times;
CJX2-80\95 (LC1-D80, LC1-D95) 10million times
---------
LC1-D AC Contactor, China AC contactor exporter, professional AC contactor manufacturer, offer AC contactor OEM/ODM service// LC1-D0910, LC1-D0901, LC1-D1210, LC1-D1201, LC1-D1810, LC1-D1801, LC1-D2510, LC1-D2501, LC1-D3210, LC1-D3201, LC1-D4011, LC1-D5011, LC1-D6511, LC1-D8011, LC1-D9511, LC1-D AC Contactor, LC1-D Contactor LC1-D AC Contactor, LC1-D contactor, LC1-F AC contactor, LC2-D AC contactor, LC2ND AC contactor, LC2NF AC contactor, LP1-D AC contactor, LA2-D air time-delay contact block, LA1-DN auxiliary contact block, LE1-D Magnetic Starter, LC3-D star-delta reduced voltage starter, LC1-DK contactor, Tianhui Electric,
Yueqing kangling electric appliance factory is located in Liushi, which is named "the City of Chinese electrical appliances"\"the city of copy products "in Wenzhou.
In order to have a good performance in the copy area of electrical appliances, we have been registed many similar famous original brands.Such as:"FAIZCO"\" ignrade" \"lheger" \""nnuljtig "\"SANME"\"KARTECH"\"CNKNGLI" \and so on.
FAIZCO is our main brand.
FAIZCO Electrical covers an area of5, 000square meters, with complete production equipment.Which is known as one of the leading manufacturers and exporters in the field of low-voltage electrical appliances in China.
Products Ranges:
Mini-Circuit Breakers, Molded Case Circuit breakers, Earth leakage Circuit Breakers, Distribution boxes, Load centers, Enclosures, AC contactors, Relays and Wall switches as well as many other electrical accessories.
Main Export Markets:
Middle East, Southeast Asia, Africa, North America, South America, etc.R&D:Our R&D team is LED by a team of experienced professors and engineers, who dedicate themselves to continually developing new products, providing customers with quality products and meeting their requirements.Quality Control:Our company has long ago established the ISO9001 Quality Management System according to the requirement of TS16949 standards and has gradually improved the quality control procedures which guarantee the quality of our products and services.
Business Principle:
Customer First!
All products can be guaranteed and graded according tocustomer requirements.Meanwhile, we can provice OEM and ODM service for buys all over the world.
FAIZCO Electrical welcome your cooperation, and win co-prosperity.
