Price: | US $ 0.002-0.23/Piece |
---|---|
Trade Terms: | FOB |
Min Order: | 30000/Piece |
Pay Type: | T/T |
Prod Model: | RS03FL70R047 |
---|---|
Markets: | North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Resistance: | Fixed Resistor |
Installation: | SMD Resistor |
Material: | Metal Film Resistor |
Package Type: | Surface Mount |
Type: | Fuse Resistor |
Brand: | Ellon |
Add to | Series | Size | Power | Tolerance | Resistance | TCR/PPM |
RS-02 | 0402 | 1/16W, 1/8W | ±1%,±5% | 50mΩ~1Ω | ±500~ ±800 | |
RS-03 | 0603 | 1/10W~1/8W | ±1%,±5% | 20mΩ~1Ω | ±500~ ±1200 | |
RS-05 | 0805 | 1/8W, 1/4W | ±1%,±5% | 10mΩ~1Ω | ±500~ ±1500 | |
RS-06 | 1206 | 1/4W, 1/2W | ±1%,±5% | 10mΩ~1Ω | ±500~ ±1500 | |
RS-0A | 2010 | 3/4W, 1W | ±1%,±5% | 10mΩ~1Ω | ±500~ ±1500 | |
RS-10 | 1210 | 1/3W, 1/2W | ±1%,±5% | 10mΩ~1Ω | ±500~ ±1500 | |
RS-12 | 2512 | 1W~ 2W | ±1%,±5% | 10mΩ~1Ω | ±500~ ±1500 |
Add to | Series | Size | Power | Tolerance | Resistance | TCR/PPM |
PR02 | 0402 | 1/16W | ±0.1%~0.5%~±1% | 24.9Ω~24.9KΩ | ±15/25/50 | |
PR03 | 0603 | 1/16W~ 1/10W | ±0.1%~±1% | 24.9Ω~332KΩ | ±15/25/50 | |
PR05 | 0805 | 1/10W~ 1/8W | ±0.1%~0.5%~±1% | 10Ω~1MΩ | ±15/25/50 | |
PR06 | 1206 | 1/8W~ 1/4W | ±0.1%~0.5%~±1% | 10Ω~1MΩ | ±15/25/50 | |
PR10 | 2010 | 1/4W | ±0.1%~0.5%~±1% | 10Ω~1.5MΩ | ±15/25/50 | |
PR12 | 2512 | 1/2W | ±0.1%~0.5%~±1% | 10Ω~1.5MΩ | ±15/25/50 |
Add to | Series | Size | Power | Tolerance | Resistance | TCR/PPM |
ARG02 | 0402 | 1/16W | ±0.5%~±1% | 4.7Ω~255KΩ | ±25/50 | |
ARG03 | 0603 | 1/10W | ±0.5%~±1% | 1Ω~1MΩ | ±25/50 | |
ARG05 | 0805 | 1/8W | ±0.5%~±1% | 1Ω~1.5MΩ | ±25/50 | |
ARG06 | 1206 | 1/4W | ±0.5%~±1% | 1Ω~2MΩ | ±25/50 |
Series | Features |
---|---|
CTR | General size , High precision , Low TCR , Low noise -for reflow /wave soldering both |
CTG | high power, Ultra precision , Low TCR , Low noise , AEC-Q200 -for reflow /wave soldering both |
Series | Features |
---|---|
HTC | High power, Compact, Higher-range resistors - for reflow |
HTE | High power, Compact, Higher-range resistors - for reflow/wave soldering both |
STC | General size, Simple structure, Low TCR - for reflow |
STE | General size, Simple structure, Low TCR - for reflow /wave soldering both |
MST | Metal plate , Low TCR , Simple structure - for reflow /wave soldering both |
HFCL | Four terminal , High power , Simple structure , Low TCR - for reflow |
HFE | Four terminal , High power , Simple structure , Low TCR - for reflow /wave soldering both |
SFC | Four terminal , High power , Simple structure , Low TCR - for reflow |
AR | Thin Film Precision Chip Resistor |
ARG | Thin Film Chip Resistor |
PR | Anti-Corrosive Thin Film Precision Chip Resistor |
TFAN | Thin Film Array Chip Resistor |
