CZ1340g-1 CZ1440g-1 Min Bench and Gap Bed Lathe Machine
Price: |
Negotiable/Piece |
Trade Terms: |
FOB,CFR,EXW |
Min Order: |
1/Piece |
Pay Type: |
L/C,T/T,D/P,Western Union |
CZ1340G-1 CZ1440G-1 Min Bench and Gap Bed lathe Machine
1) CE standard;
2) Low price with high precision;
3) Engineered from high grade casting
4) V' way bedway induction hardened and ground
5) gap bed
6) Cross and longitudinal interlocking feed with enough safety
7)inching switch for test running
8) metric and imperial threading availiable
9) precise gear driven headstock
ITEM | | CZ1340G-1 | CZ1440G-1 |
Swing over bed | mm | φ 330 | φ 355 |
Swing over carriage | mm | φ 195 | φ 220 |
Swing over gap | mm | φ 476 | φ 500 |
Width of bed-way | mm | 186 | 186 |
Distance between centers | mm | 1000 | 1000 |
Taper of spindle | | M. T. 5 | M. T. 5 |
Spindle diameter | mm | φ 38 | φ 38 |
Step of speed | | 8 | 8 |
Range of speed | rpm | 70-2000 | 70-2000 |
Head | | D 1 -4 | D 1 -4 |
Metric thread | | 26kinds (0.4-7mm) | 26kinds (0.4-7mm) |
Inch thread | | 34kinds(4-56T. P. I) | 34kinds(4-56T. P. I) |
Moulder thread | | 16 kinds(0.35-5M. P) | 16 kinds(0.35-5M. P) |
Diametral thread | | 36 kinds(6-104D. P) | 36 kinds(6-104D. P) |
Longitudinal feeds | mm-r | 0.052-1.392 (0.002" -0.0548" ) | 0.052-1.392 (0.002" -0.0548" ) |
Cross feeds | mm-r | 0.014-0.38 (0.00055" -0.015" ) | 0.014-0.38 (0.00055" -0.015" ) |
Diameter of lead screw | mm | φ 22(7-8" ) | φ 22(7-8" ) |
Pitch of lead screw | | 3mm or 8T. P. I | 3mm or 8T. P. I |
Saddle travel | mm | 1000 | 1000 |
Cross travel | mm | 170 | 170 |
Compound travel | mm | 74 | 74 |
Barrel travel | mm | 95 | 95 |
Barrel diameter | mm | φ 32 | φ 32 |
Taper of center | mm | M. T. 3 | M. T. 3 |
Motor power | Kw | 1.5(2HP) | 1.5(2HP) |
Motor for coolant system' s power | Kw | 0.04(0.055HP) | 0.04(0.055HP) |
Machine(L * W * H) | mm | 1920 * 750 * 760 | 1920 * 750 * 760 |
Stand(left) (L * W * H) | mm | 440 * 410 * 700 | 440 * 410 * 700 |
Stand(right) (L * W * H) | mm | 370 * 410 * 700 | 370 * 410 * 700 |
Machine | Kg | 500-560 | 505-565 |
Stand | Kg | 70-75 | 70-75 |
Prod Model: |
CZ1340G-1 CZ1440G-1 |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Lathe Machine: |
Bench Lathe Machine |
Type: |
Horizontal Lathe |
Power Source: |
Electric |
Controlling Mode: |
Artificial |
Automatic Grade: |
Semiautomatic |
Setting Mode: |
Floor-type |
Precision: |
High Precision |
We, Shaanxi Haven Equipment & Trading Co., Ltd, is consisted with 2 factories and 1 international trading company, so we can export our products directly at competitive price. To run our business conveniently, we set up our 2 factories in Nantong Industry Zone which is located in the most developed economic area in China and is nearby the Shanghai Sea Port, that will be much helpful to low our export cost.
With experienced engineers and worker, we produce high quality machines and supply good after sale service. In the past years, we are specialized in import and export of machinery and equipment such as machine tools, vehicles maintenance equipments, motors, bearings, hand tools, power tools and industrial materials. Our business scope also includes import and export of technology, contracting overseas projects and engineer training services.
Our products have been exported to more than 30 countries or regions in the world with high quality, We commit ourselves to cooperating with importers and exporters all over the world. We are looking forward to your enquiries and collaboration. Our technicians will assure you of appropriate equipment with reasonable prices and best pre-sale and after-sale services.
Our Business Scope Include: Turning Machines (Lathe), Drilling Machines, Drilling And Milling Machines, Boring Machines, Milling Machines, Machining Centers, Grinding Machines, Tool Grinding Machines, Gear Cutting And Finishing Machines, Planning Machines, Shaping Machines, Slotting Machines, Broaching Machines, Sawing Machines, Cut-Off Machines, Screwing And Threading Machines, Honing Machine, Polishing Machines, Shearring Machines, Press Brakes, Bending Machine, Punching Machine, Iron Worker, Presses, Rolling Machine, Notching Machine, Engraving Machines, Electric Discharging Machine (EDM), etc.
Our target is: High quality, efficient service, reliable honesty.
