Product Specifications
| Prod Model: |
DDS226DN-4P |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Brand Name: |
CNC |
| Model Number: |
Dds226dn-4p |
| Display Type: |
Digital Display: Register and LCD |
| Phase: |
Single Phase |
| Accuracy Class: |
1 |
| Output Voltage: |
110V,120V,220V,240V |
| Operating Temperature: |
-25 ~+55 |
| Type: |
Energy Meter |
| Display: |
Digital |
| Electric Equipment: |
Single-phase |
| Theory: |
Electronic Meter |
| Usage: |
Standard Electric Energy Meter |
| Installation: |
DIN-Rial Mount |
Product Description
DDS226DN-4P Single Phase Din Rail Electrical Meter
General
Din-Rail electric power meter is a new type smart electronic electric measurement terminal that adopt micro-electronics technical measuring energy power, large scale integrated circuit, digital processing technology and SMT advanced technology. Comply with National Standard GB/T17215.321 and International IEC62036 Standard. Accurately and directly measure forward direction active energy; It also can measure the current, voltage, power, frequency, power factor etc. Some of meter can choose multi-rate energy statistics, which can meet the different requirements. Step motor type register display total energy or LCD display total power consumption and each specification. This meter has advantages of high reliability, small volume, light weight, specious appearance, advanced technical, 35mm standard DIN rail installation. Also have the features of anti-interference, low consumption, high accuracy, high overload, electricity larceny prevention, and long working life.
Accuracy Class
|
1,2
|
Voltage
|
AC240V, AC220V, AC120V, AC110V
|
Current
|
1.5(6)A,5(20)A,5(40)A,5(100)A,10(30)A,15(90)A,20(100)A,
|
Frequency
|
50/60Hz
|
Starting Current
|
0.4%Ib 0.5%Ib
|
Power consumption
|
≤5VA
|
Working temperature
|
-25°C - +55°C
|
Insulation Property
|
2KV alternating voltage for 1 min, impact voltage up to 6KV
|
Standard
|
IEC62053-21, IEC62052-11, DIN EN5002, DIN43880, DIN43864
|
Communication
|
RS485 with programmable Modbus-RTU or DL/T645
|
