Has more than 20 years experience in PCB field, 1-16 layer PCB manufacturing, from 0.2~3.2mm thickness with 0.3~6.0oz copper thickness, comply with RoHS/UL, ISO9001: 2000 & ISO/TS16949: 2002, Products 100% E-test and Auto Optical Inspection.
As a technical manufacturer specializing in the printed circuit board& pcb assembly industry, Whether you need rigid pcb circuit boards, flexible PCB(FPC), rigid flex pcb circuits or aluminum clad pcb circuit boards, FZ PCB's manufacturing solutions can help.
100% E-test For PCB Board:
---We perform multiple quality assuring procedures before shipping out any PCB board. These include:
1) Visual Inspection
2) Flying probe
3) Impedance control
4) Solder-ability detection
5) Digital metallographic microscope
6) AOI (Automated Optical Inspection)
Rigid PCB from Single-sided up to 16 layers (thickness 0.4mm Min., 3.2mm Max)
Flex/Flex-rigid pcb (up to 12 layers)
HF/Impedance-control (Polar)
HDI, Halogen-free pcb circuit boards
Copper up to 6 oz
RoHS/UL, ISO9001: 2000 & ISO/TS16949: 2002
IPC 6010, IPC6012, IPC6013 Class 1-3
What will you get from FZ-PCB
· Reliable and stable quality with more than 12 years pcb manufacturing experience.
· Quick response & 24 hours available service.
· Professional sales service & advice.
· Fulfillment of our promises, NO lies.
· Protecting your Intellectual property. All our staff of trained professionals are · Working under a strict confidential contract.
Delivery Timescales
Sample
· Single layer 5 days
· Double Side 5-7days
· 4 ~ 6 layers 8-10days
· Above 8 layers 10-14days
· Aluminum PCB 7-10days
· Flexible PCB 10-14days
* Urgent Routing sample could be pushed 2-3 days earlier with premium.
Mass Production
· Single layer standard 10 days
· Double Side standard 13days
· 4~6 layers standard 15days
· Above 8 layers standard 18days
· Aluminum PCB standard 15days
· Flexible PCB standard 18days
* Material availability dependant.
Package & Shipping Method:
1. Vacuum package with silica gel, Carton box with packing belt.
2. By DHL, UPS, FedEx, TNT
3. By EMS (Usually for Russia Clients)
4. By sea for mass quantity according to customer's requirement
Payment method
1. T/T
2. Paypal
3. Western Union
|
Files |
Gerber, Protel, Powerpcb, Autocad, Orcad, etc |
|
Material |
FR-4, Hi-Tg FR-4, Lead free Materials (RoHS Compliant) , FR1, CEM-3, CEM-1, Aluminium, High frequency Material (Rogers, Teflon, Taconic), Polymide. |
|
Layer No. |
1 - 16 Layers |
|
Board thickness |
0.0075"(0.2mm)-0.125"(3.2mm) |
|
Board Thickness Tolerance |
±10% |
|
Copper thickness |
0.3OZ - 4OZ |
|
Impedance Control |
±10% |
|
Warp and Twist |
≤0.075% |
|
Peel Strength |
≥61B/in(≥107g/mm) |
|
Min Trace Width (a) |
3mil |
|
Min Space Width (b) |
3mil |
|
Min Annular Ring |
0.004"(0.1mm) |
|
SMD Pitch (a) |
0.012"(0.3mm) |
|
pcb with green solder mask and LF-FREE surface finishing BGA Pitch (b) |
0.027"(0.675mm) |
|
Register tolerance |
0.05mm |
|
Min Solder Mask Dam (a) |
0.005"(0.125mm) |
|
Solder mask Clearance (b) |
0.005"(0.125mm) |
|
Min SMT Pad spacing (c) |
0.004"(0.1mm) |
|
Solder Mask Thickness |
0.0007"(0.018mm) |
|
Hole size |
0.008"(0.20mm)-- 0.257"(6.5mm) |
|
Hole Size Tol (+/-) |
±0.003"(±0.0762mm) |
|
Max PTH Aspect Ratio |
10:1 |
|
Hole Registration |
0.003"(0.075mm) |
|
HASL |
2.5um |
|
Lead free HASL |
2.5um |
|
Immersion Gold |
Nickel 3-7um Au:1-3u'' |
|
OSP |
0.2-0.5um |
|
Panel Outline Tol (+/-) |
±0.004''(±0.1mm) |
|
Beveling |
30°45° |
|
V-cut |
15° 30° 45° 60° |
|
Surface finish |
HAL, HASL Lead Free, Immersion gold, Gold plating, Gold finger, immersion silver, immersion Tin, OSP, Carbon ink, |
|
Certificate |
ROHS ISO9001 TS16949 SGS UL |
|
Special requirements |
Buried&blind vias, Impedance control, via plug, BGA soldering and gold finger |
FZ-PCB is one of Asia' S leading full-service PCB to PCBA solution providers. Established in the year 2002, mainly provide the high-level quality PCB board and PCB assembly service to our customer which are the leading companies in the telecommunication, LED, medical treatment, aviation, instrumentation, micro-electronics and automated-control area. Our achievements are recognized through our customers' Success, industry and customer recognition, and continuous quality improvement.
