Product Specifications
Prod Model: |
1200mm*2800mm |
Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
Material: |
Non-asbestos |
Refractory Temperature: |
Over 2000 ℃ |
Grade: |
Grade A |
Type: |
Magnesium Oxide Board |
Usage: |
Building |
Surface Finishing: |
Glossy |
Thickness: |
10mm |
Appearance: |
Plate |
Edge: |
Square |
Shape: |
Square |
Color: |
Green |
Product Description
Raw Material
Raw Material | Percentage(%) |
MgO | 48 |
MgCl2 | 32 |
Perlite | 10 |
Chip | 6 |
Alkali glass fiber | 2 |
Others | 2 |
Specification
Edge: square, taper, beveled, grooved and tongue
Standard size : 900*2700mm/915*2750mm
1200*2300mm/1220*2440mm
1200*2500mm/1220*2500mm
1200*3000mm/1220*3000mm
Max width : 1220mm
Max length : 3000mm
Thickness range : 3mm-20mm
Available color : white,black,red,pink,green,blue and grey
Special size are available according to your demands.
Data Information
Heading | Unit Used | Inspection value | Standard |
Density | g/cm³ | 0.96-1.12g/cm³ | GB 8624 |
Fire ratings | grade | A1 | GB/T7019-1997 |
Thermal Resistance | m²K/W | 1.14m²K/w | GB/T13475-92 |
Bending Resistance(Dry) | ≤Mpa | 18Mpa | GB/T7019-1997 |
Bending Resistance(Fully Absorbed in Water) | ≤Mpa | 22Mpa | GB/T7019-1997 |
Sound Insulation | dB | ≥44dB | GBJ121-88 |
Absorption Moisture | ≤% | ≤15% | GB/T7019-1997 |
Tensile Strength | ≤Mpa | 8-13Mpa | GB/T7019-1997 |
Impact Resistance | kj/m² | Between 2.0-2.5 are qualified, for 4mm,our board could reach 4.5kj/m² so our boards are good. | CNS 13778 |
Main Features
1.Fireproof
ZJGLEADER MGO board adopts the A~grade non~inflammable material measured through national authoritative organizations.Its fire endurance can limit to 4 hours.No harmful smog will be generated which ensure people's safety.
2.Waterproof
ZJGLEADER MGO board has excellent dampness prevention performance.It can keep intact after being soaked in water without swelling and deformation.
3.Soundproof
ZJGLEADER MGO board can insulate sound effectively equaling to a 95mm thickness soundproof wall or a 12mm thickness gypsum board.It is equivalent to the effect of a 150mm thickness ordinary solid brick wall.
4.Insulate heat
The thermal resistance of a ZJGLEADER MGO board is 1.14m2k/w.ZJGLEADER MGO board performs well in heat insulation and warm-keeping.
5.Light weight and high strength
ZJGLEADER MGO boards' intensity of impact resistance is 2~3 times to the wall of ordinary.ZJGLEADER MGO board is easy to install which can shorten cost for a project.
6.Convenient process
ZJGLEADER MGO board is convenient to carry and cut.It can be easily installed which can reduce the cost.It is equipped with high bending resistance with lower thickness,and can be used in various types of processing.
7.Durable
ZJGLEADER MGO board has stable performance.It is acid~alkaline resistance and antiseptic.It also defends insects and ants.
Application
1.Fire resistance board series: used in the tunnel ceiling, steel structure column,beam, horizontal floor,fire partition wall, room dividers.
2.Decorative board series: used in hotels, office buildings, residential renovation.
3.Substrate Series:used in ceiling, partition, fireproof door core, warehouse board and lining board.
4.Soundabsorbing board Series: subways, bus stations, theaters, factories and other public buildings.
Why choose ZJGLEADER company?
ZJGLEADER Import and Export CO.Ltd. has a sound quality control system,normative progress operation standard,and advanced production equipment.
ZJGLEADER MGO Board has achived relevant certificates like CE,SGS and ISO9001~2000.All of them were recognized by authorities.
Our excellent product and sincere service will satisfy you if you give us a chance.So,if you have any requirements or problems,please contact me immediately!
Person:Daisy Jiang
Tel:86-512-5672 8112
Fax:86-512-5672 8511
Zhangjiagang Leader Import & Export Co., Ltd. is the key member of Leader Group Industry Co., Ltd., been dedicated to the R&D, manufacture and international trade of fire-proof material, ceiling and wall partition system since 2002. At present, we have our own factories in Zhangjiagang City.
The main products we manufacture and export as below:
A. MGO board
(Common board, Sanded board, Slurry board)
B. Ceiling
(Perforated acoustic panel, PVC ceiling, Mineral fiber ceiling)
C. SIP sandwich panel
(MGO+EPS/XPS+MGO, FCB+EPS/XPS+FCB, FCB+EPS/XPS+MGO)
D. Cladding
(Pattern: Impression, Tile, Face brick, Timber grain, Sand rock, Broken stone, Broken brick, Ceramic brick, ODD brick, Culture stone)
E. Fiber cement board/Calcium silicate board
F. Melamine MGO board
(HPL, UV, Plywood)
G. Stone coated metal roof tile
(Angle hip, Eave flashing, Valley tray, Box barge cover)
H. Accessories
(Screw, Tape, T-grid, Steel stud)
Since 2007, we have invested over $10 million with 6 workshops and 6 automatic production lines in the production of construction materials, annual output is over 20, 000, 000 sqm. " Leader" brand of products are welcomed in Southeast Asia, the US, the Middle East and other countries and regions.
We produce your orders following ISO 9001: 2008 and CIS management guidelines. We constantly insist on the principle-quality and customers first that no substandard products can be delivered to clients.
Welcome to visit our company! For further information, pls contact us now, thank you!
