Product Specifications
| Prod Model: |
ei22t202051 |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Part No.: |
Ei22t202051 |
| Size: |
29.6*22*10mm(Max) |
| Withstand Voltage: |
1.5kvdc |
| Working Temperature: |
-40 C to + 85c |
| Working Frequency: |
200k~350k |
| Inner Core: |
Flat Magnetic Core |
| Weight: |
<= 25g |
| Usage: |
Application Fo DC-DC Power |
| Phase: |
Three |
| Coil: |
Core-type Transformer |
| Cooling Method: |
Dry-type Transformer |
| Winding Type: |
Auto-transformer |
| Application: |
Audio |
Product Description
EI22-2 150W flat transformer
standards:GB/T14860 & Q/MM162-2013
Features & Application:
1. Use EIR14 planar magnetic core ,mutillayer PCB technique;
2. Use for DC/DC module power ,max output power 20W ;
3. working frequency: 300K~500K;
4. outline dimension :15*14.6*6mm (MAX);
5. withstand voltage between secondary coils :1.5KVDC;
6.Working temperature range : -40 C ~ 85 C ;
7. can offer secondary power winding ;
8. weight :<= 3.5g
ER 14 T 2 09 04 1
1 2 3 4 5 6 7
1:magnetic serials ,eg: EE, EI ,ER, EL, PQ
2: magnetic core size ,eg: 18,22,25,43...
3. T= transformer
4. no. of windings
5. no. of original windings of primary side
6. no. of secondary windings of primary sid
7. serial no.
