Product Specifications
| Prod Model: |
SCF0914E |
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Security Level: |
A1 |
| Material: |
Steel Plate |
| Function: |
Fireproof |
| Door Type: |
Single Door |
| Lock Type: |
Electronic Lock |
| Certification: |
UL |
| Appearance Of Height: |
<273mm |
| Appearance Of Width: |
<370mm |
| Appearance Of Depth: |
301-400mm |
| Password Working Principle: |
Electronic |
| Application: |
Commercial |
Product Description
Electronic Safes for home and office with fireproof protection (Scf0914e)
Model Number: SCF0914E
Minimum Order Quantity: 50 Piece/Pieces
Supply Ability: 1000 Piece/Pieces per Month
Home & Office safes /fire proof / Laser cut door /UL Electronic lock.
Laser cut single wall safes with fire fire protection, High quality Securam UL certified digital lock
1) Size & Weight:
- ExternalSize (H x W x D): 222 x 300 x 350(mm); 8.7 x13.9 x11.8(inch)
- Internal Size ( H x W x D): 184 x 314x 200(mm); 7.2 x12.4 x8.1 (inch).
- Interior Cubic feet: 0.43ft³
- Net Weight: 23± 1kg / 51± 2 lb
2) Interior and shelving
- 1 removable shelf
- 6 side carpeted walls
3) Material
- Single wall solid steel plate body & door, fire protection gypsum board, fire activated expanding door seal.
- Steel thickness: 4mmfor body, 8mm for door
4) Lock & handle
- L-shaped chrome plated diecast handle
- High quality Securam UL certified digital lock (ECSL-0601A-1U)
- no override key system to prevent unauthorized entry
5) Security feature
- Chrome plated 25mm dim solid steel boltwork,
- Inner hinge to prevent hinge cutout
- Extra strong dead bars to prevent prying attack
- Direction and q'ty of bolt ( Horizental - top - bottom - deadbar): 2-0-0-1
- Anti drilling hard plate for door.
- Indipendent spring loaded relocking device
- 30 minutes fire protection for paper documents. (Factory test)
- Fire activated expanding door seal.
6) Color and Finish
- Durable powder coat beige
- Color option: Other color available for order q'ty over than 100 PCS.
7) Accessory
- Two anchor bolt holes(13mm)on the bottom.
Two anchoring bolt and plastic bolt hole covers included...
8) Standard option:
- Customer Logo: Please contact us for MOQ and additional cost.
- Without aluminium facial plate.
- Please contact us if you have other needs.
** Sales restricted area: Australia
| Model Name | Out side size (HxWxD, mm) | Out side size (HxWxD, inch) |
| SCF0914E | 222 | 352 | 300 | 8.7 | 13.9 | 11.8 |
| SCF1418E | 352 | 452 | 350 | 13.9 | 17.8 | 13.8 |
| SCF2218E | 552 | 452 | 350 | 21.7 | 17.8 | 13.8 |
AIPU is a safes manufacturing company located in Ningbo China.
Our company consist of 3 safes factories and one safes technology research institute in Ningbo with overall 1200 employees and 45 sales branches throughout the mainland China.
We are proud of being safes manufacturer with advanced equipments such as CNC punching machines and lazer cutting machines, and we have more than one hundred safes expert engineers.
AIPU received ISO9001 quality control system and we also have products carrying UL, CE, ETL and many other overseas and Chinese certificates.
We have been building safes from 1991 and have become number 1 market share from 2005 in Chinese domestic market.
Our overall sales volume 2009 was around $52, 000, 000 and $18, 000, 000 was exported to overseas.
We are a major supplier of many large and famous safes companies such as Gunnebo, AMSEC, Stack-On, Gardall, MESA, Pheonix, etc.
Our product range covers wide varity of different safes such as gun safes, fire proof safes, depository safes, hotel safes, finger print safes, etc.
With our accumulated experience in safes building and service, we believe that we could satisfy your need and can be your supplier.
