Product Specifications
| Markets: |
North America,South America,Eastern Europe,Southeast Asia,Africa,Oceania,Mid East,Eastern Asia,Western Europe |
| Usage: |
Transportation Chain |
Product Description
1. Widely used for conveying light-weight materials in food, electronic, tobacco, printing, packaging, textiles and other industries.
2. Widely used for conveying medium-weight materials in food, electronic, tobacco, printing, packaging, textiles, dyeing, chemical, post and other industries.
3. Widely used for conveying heavy-weight materials in metallurgy, building materials, post, chemical and other industries.
Product features: One or both sides are coated with rubber or PVC, it has great strength, little elongation, good bending and long service life.
Rubber conveyor
belt |
Specification |
framework material |
elastomer |
Total
Thickness
mm |
color |
Tensile strength
N/mm |
1% elongation
at specified load
N/mm |
Temperature
Range
|
One fabric-
One rubberized |
E0
E1
E2 |
NBR/PVC |
0.5-1.5 |
Green,
White,
Or other |
80 |
4 |
-15-110 |
One fabric-
Two rubberized |
1.0-1.5 |
80 |
4 |
Two fabric-
Two rubberized |
1.5-2.0 |
160 |
8 |
Two fabric-
Three rubberized |
2.0-3.0 |
160 |
8 |
Two fabric-
One rubberized |
1.0-2.0 |
160 |
8 |
Three fabric-
Three rubberized |
3.0-3.5 |
240 |
12 |
Three fabric-
Four rubberized |
3.0-4.0 |
240 |
12 |
Three fabric-
Two rubberized |
2.5-3.0 |
240 |
12 |
Four fabric-
Four rubberized |
4.0-4.5 |
320 |
16 |
Four fabric-
Five rubberized |
4.0-5.0 |
320 |
16 |
Four fabric-
Three rubberized |
3.5-4.0 |
320 |
16 |
Five fabric-
Six rubberized |
5.0 |
400 |
20 |
