Basic function:
1. Floor display
2. Open or closed sate display of the door
3. Key switch
4. Calling response
5. Running direction display
6. Overtime running protection
7. locked protection
8. Trouble self-diagnosis
9. Emergency stop switch
10. Wrong or short phase protection
11. Motor over current protection
12. Inspection operation
13. Emergency stop circuit inspection.
Load(KGS) | Type | Cabin Clear Size | Shaft Clear Size | Overhead Height | Pit Depth | Entrance Reserved Size | Motor Power(KW) |
A(Width) | B(Depth) | C(Height) | D(Width) | E(Depth) | F | G | H |
100 | Window Type | 750 | 750 | 900 | 1250 | 900 | >=3600 | - | 750 | 1000 | 600 | 1.1 |
100 | Trolley Type | 750 | 750 | 900 | 1250 | 900 | >=3600 | 600 | 750 | 1000 | - | 1.1 |
200 | Window Type | 900 | 900 | 1000 | 1400 | 1100 | >=3600 | - | 900 | 1100 | 800 | 1.5 |
200 | Trolley Type | 900 | 900 | 1000 | 1400 | 1100 | >=3600 | 800 | 900 | 1100 | - | 1.5 |
250 | Window Type | 950 | 950 | 1000 | 1450 | 1150 | >=3600 | - | 950 | 1100 | 800 | 2.2 |
250 | Trolley Type | 950 | 950 | 1000 | 1450 | 1150 | >=3600 | 800 | 950 | 1100 | - | 2.2 |
300 | Trolley Type | 1000 | 1000 | 1100 | 1500 | 1200 | >=3600 | 1200 | 1000 | 1200 | - | 3 |
500 | Trolley Type | 1100 | 1100 | 1200 | 1600 | 1300 | >=3600 | 1200 | 1100 | 1300 | - | 4 |
Components
·Row material: 304 stainless steel
·Guide rail: standard elevator T -rail.
·Motor: single speed
·Power input: 380 volts, 3 phases, 50 hertz with 3 poles disconnect switch(different types of electric supply suiting for various state standards are available)
·Controls: microprocessor based and fully automatic at car and landings emergency stop switch
·Signal system:emergency alarm, landing indicator, in-use indicator
·Hoist way door interlocks: required at each landing
Interior of car and outside doors can be designed to suit your taste (by us or your architects/interior designers)
If you want details, please contact me.
